Note: Installing this feature is a customer task. You can complete this task yourself, or contact a service
provider to complete the task for you. You might be charged a fee by the service provider for this service.
Preparing the 8284-21A or 8284-22A system to install a disk drive or solid-state
drive with the power turned on in IBM i
Learn about the steps you must complete before you install a disk drive or solid-state drive (SSD) in a
system with the IBM i operating system or IBM i logical partition that controls the drive location
powered on.
If you are installing SSDs, review the configuration rules and then return here. For details, see
"Solid-state drive configuration rules" on page 104.
To prepare the system to install a disk drive or solid-state drive, complete the following steps:
1. Ensure that the software that is required to support the feature is installed on your system. For
information about software prerequisites, see the IBM Prerequisite website (http://www-
912.ibm.com/e_dir/eServerPrereq.nsf). If the required system firmware, software, or fix packs are not
installed on your system, go to the Fix Central website (http://www.ibm.com/support/fixcentral/) to
download and install them before you continue.
2. Determine the slot in which you want to install a disk drive or an SSD. The disk drive and SSD slots
are in the front of a system. More SSD slots are also available in an expanded function system.
Figure 18 and Figure 19 show the disk drive and solid-state drive locations and service indicators.
Service indicators are located above the latch handle on the disk drives.
Figure 18. Disk drive and service indicator locations for a base function system
Figure 19. Disk drive, solid-state drive, and service indicator locations for an expanded function system
22
Disk drives or solid-state drives
