A
Figure 148. Opening the air baffle
Closing the air baffle on an 8247-42L, 8286-41A, or 8286-42A system
Use this procedure to close the air baffle on an 8247-42L, 8286-41A, or 8286-42A system.
To close the air baffle, complete the following steps:
1. Ensure that you have the electrostatic discharge (ESD) wrist strap attached. If not, attach it now.
2. Push down the air baffle (B) toward the chassis.
3. Press the side latches (A) to latch the air baffle to the chassis.
164
Disk drives or solid-state drives
B
