DATA mode, EDGE( 1 Rx,4 Tx ) CLASS 12
GSM 850
GSM 900
DCS1800
PCS1900
DATA mode, EDGE( 3Rx, 2 Tx ) CLASS 12
GSM 850
GSM 900
DCS1800
PCS1900
UMTS Sleep Mode (without USB connection)
WCDMA 1900
WCDMA 850
UMTS Sleep Mode (with USB suspended)
WCDMA 1900
WCDMA 850
UMTS Talk
WCDMA 1900
WCDMA 850
HSDPA Data(Only 5216A)
WCDMA 1900
WCDMA 850
5.4

EMC and ESD Notes

EMC tests should be performed to detect any potential problems. Possible harmful emissions radiate by
the application to the RF receiver in the receiver band. RF emissions interfere with audio input/output. It is
recommended to shield the sensitive components and trace with common ground and user can add beads
where necessary.
SIM5215&SIM5216_Hardware Design_V2.02
@power level #8 <350mA
@power level #8 <340mA
@power level #2 <325mA
@power level #2 <290mA
@power level #8 <250mA
@power level #8 <240mA
@power level #2 <230mA
@power level #2 <210mA
Sleep @DRX=9 1.2mA
Sleep @DRX=8 2.1mA
Sleep @DRX=6 4.2mA
Sleep @DRX=9 1.2mA
Sleep @DRX=8 2.0mA
Sleep @DRX=6 4.4mA
Sleep @DRX=9 1.9mA
Sleep @DRX=8 2.6mA
Sleep @DRX=6 4.6mA
Sleep @DRX=9 1.9mA
Sleep @DRX=8 2.7mA
Sleep @DRX=6 4.8mA
@Power 23dBm Typical 580mA
@Power 10dBm Typical 205mA
@Power-55dBm Typical 174mA
@Power 23dBm Typical 510mA
@Power 10dBm Typical 195mA
@Power-55dBm Typical 131mA
@Power 23dBm Typical 584mA
@Power 10dBm Typical 331mA
@Power-55dBm Typical 179mA
@Power 23dBm Typical 536mA
@Power 10dBm Typical 231mA
@Power-55dBm Typical 165mA
