4

RF Specifications

4.1

LTE RF Specifications

Table 21: Conducted transmission power
Frequency
LTE-FDD B2
LTE-FDD B4
LTE-FDD B5
LTE-FDD B13
Table 22: Operating frequencies
Frequency
LTE-FDD B2
LTE-FDD B4
LTE-FDD B5
LTE-FDD B13
Table 23: Reference sensitivity (QPSK)
E-UTRA
band
1.4 MHz
2 -102.7
4 -104.7
5
-103.2
13
4.2

LTE Antenna Design Guide

Users should connect antennas to Module's antenna pads through the micro-strip line or other types
of RF trace. The trace impedance must be controlled in 50Ω. SIMCom recommends that the total
insertion loss between Module and antenna should meet the following requirements:
Table 25: Trace Loss
Frequency
700MHz-960MHz
1710MHz-2170MHz
SIM7600V-H_User Manual_V1.00
Power
23dBm +/-2.7dB
23dBm +/-2.7dB
23dBm +/-2.7dB
23dBm +/-2.7dB
Receiving
1930 ~1990 MHz
2110~2155 MHz
824～849 MHz
777~787MHz
3GPP standard
3MHz 5MHz 10MHz
-99.7 -98 -95
-101.7 -100 -97
-100.2 -98 -95
-97 -94
Loss
<0.5dB
<0.9dB
Smart Machine Smart Decision
Min.
<-40dBm
<-40dBm
<-40dBm
<-40dBm
Transmission
824~849 MHz
1850 ~1910 MHz
869～894MHz
746~757MHz
Test value 3GPP standard
10 MHz 15 MHz
-101 -93.2
-102 -95.2
-99
-99
37
Duplex
20 MHz
-92 FDD
-94 FDD
FDD
FDD
