Operating Guide
PSB 10000 4U
Bidirectional DC Power Supply
Note: everything marked in red in this document is either not
confirmed or may change due to hardware and software opti-
mizations, until the final issue of this document is released.
Doc ID: PSB1EN
Revision: 01
Date: 08/2019
