THORLABS PM200 Quick Reference page 14

PM200
W (nW, µW, mW)
A (nA, µA, mA)
dBm (1mW = 0 dBm)
Thermal sensors - they deliver a voltage proportional to the incident power:
W (nW, µW, mW)
V (mV)
dBm (1mW = 0 dBm)
Pyroelectric sensors - they deliver a voltage peak, proportional to the incident
pulse energy:
J (mJ)
V (mV)
Power / Energy Density
The calculation is based on the beam parameters, entered in Measurement
Settings panel (
Beam shapes can be selected from a drop-down menu:
To change the beam dimension, click into the numeric field - an editor comes up:
12
and in the next panel ):
© 2011 Thorlabs
