PM200
3.5
Measurement Views
This menu can be reached via the
button.
The different measurement views can be easily selected after pressing the
"views"
button. For most applications the "numeric " and the "needle "
10
14
view will be the best choice for an excellent visible and quickly configurable
power or energy readout. The interactive touch areas allow fast access to all
settings and the drag and drop box gives up to 6 useful, free configurable extra
displays.
From this panel, also graph and statistics measurement panels
can be
14
selected. Additionally, the File Manager
and the Calculator
can be started.
17
16
3.5.1 Numeric View
The upper part of the display important measurement settings are displayed.
10
© 2011 Thorlabs
