Summary of Contents for CHIEF LW46U P Series
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S 46"/47"/48"/49"/50"/55" Portrait Wall Kiosks Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description LW46/47/48/49/50/55UxP...
-
Page 2: Important Safety Instructions
Do not use this mounting system outdoors. ACCESSORY: AN ACCESSORY is the secondary Chief product which is attached to a primary Chief product, and may have a component attached or setting on it. IMPORTANT ! : The LW46/47/48/49/50/55UxP portrait wall... - Page 3 Installation Instructions LW46/47/48/49/50/55UxP DIMENSIONS LW46UxP 46.50 1181.1 22.50 571.5 DIMENSIONS: INCHES 27.50 [MILLIMETERS] 698.5 LW47UxP 46.50 1181.1 23.00 584.2 27.50 DIMENSIONS: INCHES 698.5 [MILLIMETERS]...
- Page 4 LW46/47/48/49/50/55UxP Installation Instructions DIMENSIONS--continued LW48UxP 46.50 1181.1 23.50 596.9 DIMENSIONS: INCHES 27.50 [MILLIMETERS] 698.5 LW49UxP DIMENSIONS: INCHES [MILLIMETERS]...
- Page 5 Installation Instructions LW46/47/48/49/50/55UxP DIMENSIONS--continued LW50UxP DIMENSIONS: INCHES [MILLIMETERS] LW55UxP 54.25 1378.0 26.84 681.8 DIMENSIONS: INCHES 32.50 [MILLIMETERS] 825.5...
-
Page 6: Tools Required For Installation
LW46/47/48/49/50/55UxP Installation Instructions LEGEND Phillips Screwdriver Drill Hole Destornillador Phillips Perforar Kreuzschlitzschraubendreher Bohrloch Chave de fendas Phillips Fazer furo Cacciavite a stella Praticare un foro Kruiskopschroevendraaier Gat boren Tournevis à pointe cruciforme Percez un trou Open-Ended Wrench Hex-Head Wrench Llave de boca Llave de cabeza hexagonal Gabelschlüssel Sechskantschlüssel... -
Page 7: Assembly And Installation
Installation Instructions LW46/47/48/49/50/55UxP ASSEMBLY AND INSTALLATION Preparing Wall Bracket Remove kiosk from the packaging and place on a flat surface. (See Figure 1) Open so that wall bracket is at a 90° angle from the swing door. Keeping the wall bracket at 90°, slide the wall bracket about 1 inch towards bottom of kiosk until hinge pins clear the hinges, and move the wall bracket away from the swing door. - Page 8 LW46/47/48/49/50/55UxP Installation Instructions Installing Wall Bracket The LW46/47/48/49/50/55UxP wall kiosk mounts are designed to be mounted to: Center wall bracket over desired location on wall • a bare 8" concrete or 8"x8"x16" concrete block wall; or • a 2" x 4" wood studs (16" on center minimum) wall with a maximum drywall thickness of 5/8";...
- Page 9 Installation Instructions LW46/47/48/49/50/55UxP IMPORTANT ! : Attaching the wall bracket requires a IMPORTANT ! : Refer to Fastener Installation Methods (located in Appendix at end of Installation Instructions) minimum of 8 wall fasteners. For installation in a wood or for details on installing snap toggles and related steel stud applications, the snap toggles are required fasteners into various wall types.
- Page 10 LW46/47/48/49/50/55UxP Installation Instructions Carefully lay flat panel face down into the depth-adjustable Place hinged frame onto back of flat panel and match the outer frame. (See Figure 7) VESA pattern on flat panel to the hinged frame mounting slots. Also match the threaded studs in outer frame to the hooks on the hinged frame.
- Page 11 Installation Instructions LW46/47/48/49/50/55UxP Cabling Tighten thumb nuts over threaded studs in four locations on the hinged frame. (See Figure 9) Cables may be placed through the center slot in the wall 10. Replace and fasten four Phillips screws which were bracket flanges.
- Page 12 LW46/47/48/49/50/55UxP Installation Instructions APPENDIX Switching Hinge Location Remove AND SAVE the hardware on the latch (right) side Remove and of the wall bracket. (See Figure 12) SAVE two hinges Wall bracket Hinge Wall bracket Figure 13 Remove and SAVE lift-off hinge and hinge spacer plate from two locations on swing door.
- Page 13 Installation Instructions LW46/47/48/49/50/55UxP Replace two lift-off hinges and hinge spacer plates onto opposite side (left) of swing door. (See Figure 15) Fasten in place with four (two each hinge) NEW 10-32 x 3/4" button head cap screws (CB). (See Figure 15) (CB) x 4 Hinge spacer...
- Page 14 LW46/47/48/49/50/55UxP Installation Instructions 10. Flip and install latch section on left side of wall bracket. 14. Re-install inside latch: (See Figure 17) NOTE: a. Place spring on top of horizontal tab and compress Be sure that upper and lower tabs are slid into slots on spring slightly.
- Page 15 Installation Instructions LW46/47/48/49/50/55UxP Fastener Installation Methods Steel Stud IMPORTANT ! : See Table 1 for appropriate hardware IMPORTANT ! : See Site Requirements for Steel Stud and pilot hole sizes for various wall types. Installation section before proceeding with Steel Studs installation to ensure installation site meets requirements! Wood Stud The drywall must have a minimum thickness of 1/2"!
- Page 16 LW46/47/48/49/50/55UxP Installation Instructions Line up anchor with attachment point. Insert 1/4-20 x 1-3/4" Phillips pan head screw (AD) through 1/4" washer (AE), corresponding mounting hole in wall Steel stud bracket and into anchor (AC), and tighten until flush against (if present) wall bracket.
- Page 17 Installation Instructions LW46/47/48/49/50/55UxP...
- Page 18 LW46/47/48/49/50/55UxP Installation Instructions...
- Page 19 Installation Instructions LW46/47/48/49/50/55UxP...
- Page 20 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief, a products division of Asia Pacific A Office No. 918 on 9/F, Shatin Galleria Milestone AV Technologies 18-24 Shan Mei Street...
