I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
LBM2X2U
LBM3X3U
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
LBM3X2U
LBM3X1UP
LBM2X2UP
Bolt Down Video Wall
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
LBM Series
LBM3X2UP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LBM Series and is the answer not in the manual?

Questions and answers

Summary of Contents for CHIEF LBM Series

  • Page 1 Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation LBM2X2U LBM3X1UP LBM3X2U LBM2X2UP LBM3X3U LBM3X2UP Bolt Down Video Wall Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description LBM Series...
  • Page 2: Important Safety Instructions

    MODEL Max Weight Max Weight the information contained in this document. Allowed for EACH Capacity of Chief® is a registered trademark of Milestone AV Technologies. Display Mounting System All rights reserved. LBM2X2U 125 lbs 500 lbs (56.7 kg)
  • Page 3: Installation Instructions

    WARNING: Do not use this product outdoors. NOTE: The UL listed LBM Series video walls may be used with the UL Listed accessories FCAX20, FCAX14, FCAX08. LBM3X2U may be used with UL listed FCA3X1U and LBM2X2U may be used with UL listed FCA2X1U.
  • Page 4 LBM Series Installation Instructions LBM3X2U MAX WEIGHT: 125 LBS PER DISPLAY 750 LBS TOTAL 108.89 15.75 2765.8 400.0 5.38 3.73 MAX MOUNTING 136.5 94.7 PATTERN HEIGHT 88.27 66.62 64.38 1.50 2242.1 2.53 1692.0 1635.1 38.1 64.1 65.88 SCREEN CENTER 1673.2 MAX HEIGHT 16.38...
  • Page 5 Installation Instructions LBM Series LBM3X1UP MAX WEIGHT: 125 LBS PER DISPLAY 64.38 1635.1 SCREEN CENTER MAX HEIGHT 17.38 MAX WEIGHT: LBM2X2UP 100 LBS PER DISPLAY 82.38 SCREEN CENTER MAX HEIGHT 17.38...
  • Page 6 LBM Series Installation Instructions LBM3X2UP MAX WEIGHT: 100 LBS PER DISPLAY 82.38 2092.3 SCREEN CENTER MAX HEIGHT 17.38...
  • Page 7 Installation Instructions LBM Series Bolt Down Dimensions BOTTOM VIEW LBM2X2U/LBM3X1UP FOR BOLT DOWN INSTALLATION LBM2X2UP/LBM3X2UP LARGER RADIUS FACES FRONT TO ATTACH TO COLUMN. 8.00 COLUMN BOLT PATTERN NOT SQUARE 203.2 6.00 8.00 152.4 203.2 0.500 12.7 1.00 28.00 25.4 711.2 1.00...
  • Page 8 LBM Series Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
  • Page 9: Tools Required For Installation

    Installation Instructions LBM Series TOOLS REQUIRED FOR INSTALLATION 1/2" (12.7mm) 3/8" (9.5mm) 3/16" (included with all) 1/8" (included with 3x2U,3x3U) 5/32" (included with 3x3U, 2x2UP, 3x2 UP) 3/8" (9.5mm) PARTS - Non-portrait Models - LBM2X2U/LBM3X2U/LBM3X3U (Portrait Models on next page)
  • Page 10 LBM Series Installation Instructions Parts - Portrait Models - LBM3X1UP/LBM2X2UP/LBM3X2UP Hardware bag (letters correspond to letters on bag) D (12/16/24) E (12/16/24) B (12/16/24) A (12/16/24) M6x16mm C (12/16/24) 1/4" .750x.344x.5 M6x12mm *Quantities are listed as M6x30mm (LBM3X1UP/LBM2X2UP/LBM3X2UP) F (12/16/24)
  • Page 11: Assembly And Installation

    (Figure 20), mark four holes at outside hole locations for each column. (See Figure 2) and (See Figure 21) WARNING: Do NOT install LBM Series mounts to any surface other than concrete! Concrete flooring must be at least 4" in thickness and NOT be covered with any other type of flooring material.
  • Page 12 LBM Series Installation Instructions Column Add-On Installation (LBM3X3U/ LBM2X2UP/LBM3X2UP only) (rear view) Insert one column add-on (V) to each column (M) making sure holes are lined up on each side. (See Figure 4) Use 5/32" hex key (J) and six 1/4-20 x 1/2" flat head cap...
  • Page 13 Installation Instructions LBM Series (AA) (BB) x 2 (FF) (K or L) display (CC) x 2 height Figure 7 Use four 5/16-18 x 3/4" button head flange screws (BB) to secure each attached clamp bracket (P) to each quick connect base (Q). (See Figure 8)
  • Page 14: Display Installation

    LBM Series Installation Instructions Add-On Rail Installation (LBM3X2U/LBM3X3U only) CAUTION: Using screws of improper diameter may Install add-on rails (DD) to right column following damage your display! Proper screws will easily thread into instructions in Rails Installation section. display mounting holes.
  • Page 15 Installation Instructions LBM Series (portrait models) (A-C or F-H) x 4 (D) x 4 (E) x 4, if necessary Figure 13 WARNING: Exceeding the weight capacity can result in LBM2X2U LBM3X2U serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the combined weight of...
  • Page 16: Cable Management

    LBM Series Installation Instructions Adjustments Starting from the bottom and working up, hang interface brackets (Y and Z) to display rails (K or L). (See Figure 14) Height Adjustment Use 1/4-20 x 1 1/4" socket head cap screws (I) to secure interface brackets (Y and Z) to rails for each display.
  • Page 17 Installation Instructions LBM Series Additional Cable Management Options Cables may be routed through tops of columns and out through the back cable management hole. (See Figure 18) (KK) Figure 20 Figure 18 If rails needed to be installed on top of cable management holes, cables may be routed through quick connect bases (Q) prior to the rails being installed.
  • Page 18 LBM Series Installation Instructions FRONT Figure 21...
  • Page 19 Installation Instructions LBM Series...
  • Page 20 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
