- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Lateral Shift Bracket Accessory LSB101...
-
Page 2: Important Safety Instructions
Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the combined weight of all components attached to the LSB101 does not exceed 50 lbs (22.68 kg) •... - Page 3 Installation Instructions LSB101 DIMENSIONS DIMENSIONS: [MILLIMETERS] INCHES LEGEND Tighten Fastener Phillips Screwdriver Apretar elemento de fijación Destornillador Phillips Befestigungsteil festziehen Kreuzschlitzschraubendreher Apertar fixador Chave de fendas Phillips Serrare il fissaggio Cacciavite a stella Bevestiging vastdraaien Kruiskopschroevendraaier Serrez les fixations Tournevis à pointe cruciforme...
-
Page 4: Tools Required For Installation
LSB101 Installation Instructions TOOLS REQUIRED FOR INSTALLATION 5/32" - security (included) PARTS A (1) [LSB101 bracket] B (1) [LSB101 bracket] G (1) C (2) 5/32" 10-32 x 1" (security) F (2) D (2) E (2) [Thumb nut] 10-32 x 1"... -
Page 5: Assembly And Installation
Installation Instructions LSB101 ASSEMBLY AND INSTALLATION The LSB101 may be used in either a lateral shift application or a forward/backward shift application. NOTE: For a lateral shift application, proceed to Attaching LSB101 - Lateral Shift. Attaching LSB101 - Forward/Backward Shift Attach one thumb nut (F) with one 8-32 x 3/8"... - Page 6 Attaching RPMA (not included) to LSB101 Ensure that lock lever on RPMA is moved to "Unlocked" position. Slide RPMA onto LSB101 brackets (A and B).(See Figure 5) Move the lock lever to "Locked" position and turn key to lock. Lock Lever ("Locked"...
- Page 7 Installation Instructions LSB101...
- Page 8 F 877.894.6918 / 952.894.6918 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 Chief, a products division of F +31 (0) 495 580 845 Milestone AV Technologies Asia Pacific A Office No. 1 on 12/F, Shatin Galleria...
