Tally Dascom DT-330 User Manual page 46

Tally Dascom DT-330
System Setup
Parameter
Energy Saving
Darkness
Print Mode
Emulation
Left Margin
Device Configuration
Parameter
Black mark Option
BM To First Line Offset
BM To Tear Offset
Cutter Option
（ 5 ） Save the parameters and click "←" at the upper right corner to return to the menu. Click
"Disconnect", the printer will restart to execute the new parameters.
Default Selectable parameters and Annotation
10min Select the time before entering energy-saving
mode without any data communication and button
action, or directly cancel the energy-saving mode.
◆ Off ◆ 1 min ◆ 2 min ◆ 5 min ◆ 10 min
2 Selectable range is 1~4.
Quality
◆ Quality Priority：The print quality is best, while
Priority
the print speed will be lowered.
◆ Speed Priority：The print speed is fastest, while
the print quality will be decreased.
ESC/POS
◆ ESC/POS
0.0mm Selectable range is 0 ~ 80mm.
Default Selectable parameters and Annotation
Disable
◆Disable ◆Enable
-4.0mm Selectable range is -4 ~ 50mm.
90.0mm Selectable range is -18 ~ 150mm.
Partial Cut
◆Disable ◆Full Cut ◆ Partial Cut
33
User Guide V1.0
