2.4 Adjusting the Paper Near-End Sensor

Adjust the Paper Near-End Sensor to suit the diameter of the roll paper used and the placing
direction the printer is installed.
Follow the steps below to adjust the paper roll near-end detector.
1.
Open the paper roll cover, and remove the paper roll.
2.
You will see a lever inside as shown below.
aper Near-End Lever
P
3.
Adjust the lever according to your need.
Adjustments position
1 (Minimum)
2
3
4
5
6 (Maximum)
Remaining amount of paper
(outer diameter: mm)
Approx. 26
Approx. 27
Approx. 28
Approx. 30
Approx. 32
Approx. 33
