Component
IRIS 1000 Cabinet
IRIS 1200 Cabinet
Monitor
Keyboard
Mouse
Transceiver
Table 3-1: IRIS Terminal Component Specifications

3.1 Hardware Components

Each IRIS Terminal system has four hardware components (see Figure 3-1).
• The Electronics Cabinet is a floor-standing unit with a 10-slot (IRIS
1000) or 20-slot (IRIS 1200) backplane and a power supply. The
Cabinet uses forced air cooling and is mounted on casters.
• The Monitor is a high-resolution 19-inch color monitor.
• The Keyboard is an 83-key up-down encoded keyboard.
• The Mouse is a 3-button mouse.
Two hardware component options are the Dial Box and Switch Box.
• The Dial Box (optional) has 8 independently programmable valuators
for sending analog information to an application program for the
IRIS Terminal.
• The Switch Box (optional) has 32 independently programmable
switches and 32 independently programmable LED indicator lights.
An 8 character LED display gives status information for the Dial Box
and the Switch Box.

3.2 Ethernet Equipment

The IRIS Terminal can be connected to an Ethernet local area network with an
Ethernet transceiver and drop cable.
Version 1.3

3. IRIS Terminal Specifications

Height
21.0"
29.0"
18.0"
1.5"
1.0"
2.0"
Width Length
10.0" 27.0"
18.0" 27.0"
20.0" 21.0"
19.0" 8.5"
2.0" 3.0"
7.0" 4.0"
Weight
100.0 lbs
200.0 lbs
97.0 lbs
3.0 lbs
0.5 lbs
0.8 lbs
