This section describes how to install and connect the components that make up
an IRIS Terminal system (see Figures 4-1a and 4-1b). Prior to installation, each
component should be unpacked and placed near its final location. Since the
IRIS Terminal components are delivered assembled, they only need to be
connected with the cables provided in the delivery cartons.
WARNING: Do not connect the IRIS Terminal to an
external power source until each cable has been
connected and checked.

4.1 Keyboard to Monitor Connection

The Keyboard cable is connected to the IRIS Control Panel located on the lower
left front of the Monitor (see Figure 3-2).
1. Connect the DIN plug on the Keyboard cable to the DIN socket
labeled

4.2 Mouse to Monitor Connection

The Mouse cable is connected to the IRIS Control Panel located on the lower
left front of the Monitor (see Figure 3-2).
1. Connect the slide-locking D socket on the Mouse cable to the D plug
labeled

4.3 Monitor to Cabinet Video Connections

The color-coded bundle of coaxial video cables is connected between the
Cabinet I/O Panel and the Monitor Back Panel (see Figures 3-3, 3-4a, 3-4b, 4-1a
and 4-1b).
1. For single Monitor operation, set all of the input impedance switches
to the
If several Monitors are connected in a series (daisy chain), set the
input impedance switches to the
Monitor, which should be set to the
Version 1.3

4. Hardware Installation

on the IRIS Control Panel.
Keyboard
on the IRIS Control Panel.
Monitor
position.
75 Ω
position for all but the last
High
position.
75 Ω
