4.10 Cabinet to Dial and Switch Box Connection (optional)
The IRIS Terminal can be connected to an optional Dial and Switch Box for
sending information to an application program for the IRIS Terminal.
1. Connect the 37-pin flat cable from the port on the Dial Box to the
bottom left port on the Switch Box.
2. Connect the 9-pin cable from the top left port on the Switch Box to
Port 2
3. Plug the 3-wire AC power cable on the Switch Box into the
convenience outlet on the Cabinet Power Panel (See Figure 3-4b).
on the Cabinet I/O Panel.
