Operation
Reply with serial. The window will be redrawn and a prompt will
appear in the upper left-hand corner.
To reboot the IRIS Terminal, press the
and repeat the boot procedures outlined above.

6.5 IP/TCP

The IRIS Terminal can be connected to an Ethernet local area network with the
IP/TCP protocols.
1. Connect the Ethernet drop cable to the Ethernet port on the Cabinet
I/O Panel (see Section 4.7).
2. Set the Monitor
to the
3. Set the Cabinet
the
On
4. Boot the IRIS terminal program (iris) with either the serial download
utility (dliris; see Section 6.2) or a floppy disk (see Section 6.4).
5. The IRIS terminal program will prompt to find the IRIS Terminal's
internet address: The syntax is x.x.x.x, i.e. four numbers separated
by periods. If the representation of a host name in the 4.2BSD
/etc/hosts table is 42.3, then the address given is "42.0.0.3".
6. If the network has a gateway address, it should be entered to inform
the IRIS terminal program.
7. Enter the network address of the host that the IRIS Terminal will be
connected to.
8. A login prompt will appear in the upper left-hand corner of this
window.
To use the IRIS Terminal, login to an account.
To reboot the IRIS Terminal, press the
and follow the boot procedures outlined above.

6.6 Monitor Adjustment

The Monitor Control Panel on the right side of the Monitor has several knobs
for adjusting the brightness and contrast of the Monitor.
Version 1.3
Power
position.
On
switch located on the front of the Cabinet to
Power
position.
Enter local host's IP address: 42.0.0.3
Enter the local gateway's network hardware address: 0.0.0.0
Enter host name: 42.0.0.2
login:
IRIS TERMINAL GUIDE
button on the IRIS Control Panel
Reset
switch located on the Monitor Control Panel
button on the IRIS Control Panel
Reset
29
