5. Remove the two system locking clips from the lower corners of the chassis
(
). You can use a Phillips head screwdriver for leverage to help you
FIGURE 2
pull out each clip.
Removing the System Locking Clips
FIGURE 2
J4200 Tray
Locking Clip
Locking Clip Installed
Replacing a J4200 Array Chassis
Mounting Rail
5
