10. After you have removed all of the components from the chassis, remove the
chassis from the cabinet (
Caution – The empty weight of a chassis is 9kg (20 lbs). You might need two people
to remove the chassis from the cabinet.
a. From the front of the cabinet, loosen the two captive screws on each side of
b. Grasp each side of the chassis and pull it toward you, and remove it from
FIGURE 7
c. Package the failed chassis and return it to Sun, if instructed to do so, or
10 Sun Storage J4200 Array Chassis Replacement Guide • April 2008
the tray.
the cabinet.
Removing the Failed Chassis From the Cabinet
properly dispose of the failed chassis.
).
FIGURE 7
