THORLABS PM100USB Operation Manual page 16

PM100USB
Voltage Input (Pyroelectric Sensors)
Connector
Units
Measurement Ranges
Display Resolution
AD Converter
Accuracy
Trigger Threshold
Input Bandwidth (Analog)
Input Impedance
Wavelength Correction
Beam Diameter Setting
Sensor Temperature Control
Supported temperature sensor
Temperature measurement range
Interface
Type
Connector
Power Supply
External power supply
Accessories
USB cable A to Mini-B, 2 m
USB Stick with
- Application Software
- Instrument Drivers
- Thorlabs Instrument Communicator
- Thorlabs DFU (Device Firmware Upgrade) Wizard
General
Operating Temperature Range
Storage Temperature Range
Dimensions (W x H x D)
Weight
Relative Humidity
Operation Altitude
1
) non-condensing
All technical data are valid at 23 ± 5°C and 45 ± 15% rel. humidity (non condensing)
14
Ranges selectable in J or V, sensor dependent
1
)
max. 80 % up to 31° C, decreasing to 50 % at 40° C
DB9F, left side
J, J/cm², W, W/cm², V
4 decades; 100 mV - 100V
100 µV / responsivity value (V/J)
16 bit
± 0.5 % f.s.
0.1 % to 99.9 % f.s.
3 kHz
W
1 M
Sensor depending; nm, (V/J)
1/e²
Thermistor
-10°C ... +80°C
USB2.0
Mini USB, left side
5V DC via USB
0 to + 40 °C
-40 to +70 °C
93.1 mm x 60.4 mm x 28.7 mm
(3.67" x 2.38" x 1.13")
approx. 0.15 kg
< 3000 m
© 2017 Thorlabs
