- Page 1 R23X Door Phone User Manual WWW.ACTIVEONLINE.COM.AU 1300 816 742...
-
Page 2: About This Manual
About This Manual Thank you for choosing Akuvox’s products. In user manual, we provides all functions and configurations you want to know about R23X. Please verify the packaging content and network status before setting. This manual applies to firmware 26.0.0.96 or lower version. -
Page 3: Table Of Contents
Content 1. Overview ....................1 1.1. Product Description......................1 1.2. Feature..........................3 1.3. Panel Description.........................4 2. Configuration ................... 5 2.1. Web login..........................5 2.1.1 Obtain the IP address....................5 2.1.2 Login the web......................5 2.2. Status............................6 2.2.1 Basic..........................6 2.3. Intercom..........................7 2.3.1 Basic..........................7 2.3.2 LED Setting......................... 8 2.3.3 Relay&Input........................9 2.3.4 AEC Setting....................... -
Page 4: Overview
1.1. Product Description R23C R23P Akuvox's Audio Doorphone R23X is an open, non-proprietary and IP-based door station for two-way communication and remote entry control. It is a perfect complement to any SIP system and offers new possibilities of effectively control entry... - Page 5 FCC Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equ ipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 6: Feature
1.2. Feature Highlight Vandal resistant body, with a flush button POE(IEEE802.3af, Power-over-Ethernet) Two-way audio communication over IP network with Echo cancel feature Complied with SIP Standard for easy integration in each SIP PBXes Physical&Power ... -
Page 7: Panel Description
Network Features 1x10/100Mbps Ethernet Port Protocols support: IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP Application Scenarios Office door phone with on-site or hosted IP-PBX Remote site entry over Internet ... -
Page 8: Configuration
2.1. Web login 2.1.1 Obtain the IP address The Akuvox R23X uses Static IP by default, the default IP address is 192.168.1.100. If the IP address is unknown, press and hold the call button for a short period of time(about 5s) after LED light turns blue, the phone will announce its IP. -
Page 9: Status
2.2. Status 2.2.1 Basic Status can be viewed from “Status -> Basic”,including the information of product, network and account. Sections Description Product Information To display the device’s information such as Model name, MAC address (IP device’s physical address), Firmware version and Hardware version. -
Page 10: Intercom
choose one account or Auto mode for the following Intercom basic settings. No Answer Call ： R23X will call to the No answer call number in order when the ringtone is time out without answer of the push button number. Disable by default. -
Page 11: Led Setting
tone is over the Dial in Time without answer. The call will be hang up. Dial out Time: When R23X calls to the other party, if the ringtone is over the Dial out Time without answer. R23X will continue calls to no answer call number in order. -
Page 12: Relay&Input
Relay Delay(sec): Allows the door to remain “open” for certain period . The range is from 1 to 5 seconds. DTMF Option: R23X support 1digit or 4 digits DTMF unlock code. Please select one type and enter the corresponding code. - Page 13 Note: Users can modify username and password in web relay website. Input There is a sensor that used for anti-vandal in R23X. When R23X is broken by violent means, the sensor will be triggered, then the management center will receive the alarm.
-
Page 14: Aec Setting
2.3.4 AEC Setting Sections Description AEC Level AEC(Configurable Acoustic and Line Echo Cancelers) is used to adjust the echo effect during the communication. The default value is 700. Increase the level, the echo control is better. -
Page 15: Multicast
2.3.5 Multicast Sections Description Multicast Audio Receiving To display and configure the Multicast setting. Multicast Receiver Enable: Enable receiver multicast function. Receiver address : Setup the multicast address. Receiver port : setup the multicast address port. Multicast Audio Sending To setup the multicast parameters. -
Page 16: Card Setting(R23C Only)
Card Issuing: Choose Card Issuing mode when writing card Card Setting IC Key DoorNum: R23X can support to connect 2 doors. Choose one and add the valid card for unlock. IC Key Name: To setup corresponding name for the card. -
Page 17: Account
2.4. Account 2.4.1 Basic Sections Description SIP Account To display and configure the specific Account settings. Status: To display register result. Display Name: Which is sent to the other call party for display. Register Name: Allocated by SIP server provider, used for ... - Page 18 SIP Server 1 To display and configure Primary SIP server settings. Server IP: SIP server address, it could be an URL or IP address. Registration Period: The registration will expire after Registration period, the IP phone will re-register automatically within registration period.
-
Page 19: Account-Advanced
2.4.2 Account-Advanced... - Page 20 Sections Description SIP Account Select an account to display the settings. Codecs To display and configure available/unavailable codecs list. Codec means coder-decoder which is used to transfer analog signal to digital signal or vice versa. Familiar codecs are PCMU(G711U), PCMA(G711A), G722 (wide-bandth codecs), G729 and so on.
- Page 21 Anonymous Call Rejection: If enabled, all incoming anonymous-out call of the designated account will be rejected. Missed Call Log: To display the miss call log. Prevent SIP Hacking: Enable to prevent SIP from hacking. Session Timer To display or configure session timer settings. Active: To enable or disable this feature.
-
Page 22: Network
2.5. Network 2.5.1 Basic Sections Description LAN Port To display and configure LAN Port settings. DHCP: If selected, IP phone will get IP address, Subnet Mask, Default Gateway and DNS server address from DHCP server automatically. Static IP: If selected, you have to set IP address, Subnet ... -
Page 23: Advance
2.5.2 Advance Sections Description Local RTP To display and configure Local RTP settings. Max RTP Port: Determine the maximum port that RTP stream can use. Starting RTP Port: Determine the minimum port that RTP stream can use. SNMP To display and configure SNMP settings. - Page 24 VLAN To display and configure VLAN settings. Active: To enable or disable VLAN feature for designated port. VID: To configure VLAN ID for designated port. Priority: To select VLAN priority for designated port. Note: Please consult your administrator for specific VLAN settings in your networking environment.
-
Page 25: Phone
2.6. Phone 2.6.1 Time/Lang Sections Description To configure NTP server related settings. Time Zone: To select local Time Zone for NTP server. Primary Server: To configure primary NTP server address. Secondary Server: To configure secondary NTP server address, it takes effect if primary NTP server is unreachable. -
Page 26: Call Feature
2.6.2 Call Feature Sections Description Mode Mode: Select the desired mode. DND (Do Not Disturb) allows IP phones to ignore any incoming calls. Return Code when DND: Determine what response code should be sent back to server when there is an incoming call if DND on. -
Page 27: Voice
callee will be muted. Others Return Code When Refuse: Allows user to assign specific code as return code to SIP server when an incoming call is rejected. Auto Answer Delay: To configure delay time before an incoming call is automatically answered. Auto Answer Mode: To set video or audio mode for auto ... -
Page 28: Phone-Multicast
2.6.4 Phone-Multicast Sections Description Multicast Setting To display and configure the Multicast setting. Paging Barge: Choose the multicast number ,range from 1 to 10. Paging priority Active: Enable o disable the multicast. Priority List To setup the multicast parameters. Listening Address: Enter the IP address you need to ... -
Page 29: Phone-Call Log
To display call history records. Available call history types are All calls, Dialed calls, Received calls, Missed calls, Forwarded calls. Users can check the call history in detail. Tick the number to delete or delete all logs. R23X supports 100 call logs. -
Page 30: Upgrade
2.7. Upgrade 2.7.1 Basic Sections Description Upgrade To select upgrading zip file from local or a remote server automatically. Note: Please make sure it’s right file format for right model. Firmware version To display firmware version, firmware version starts with MODEL name. -
Page 31: Advance
2.7.2 Advance Sections Description PNP Option To display and configure PNP setting for Auto Provisioning. PNP: Plug and Play, once PNP is enabled, the phone will send SIP subscription message to PNP server automatically to get Auto Provisioning server’s address. By default, this SIP message is sent to multicast address 224.0.1.75(PNP server address by standard). - Page 32 This setting require DHCP server to support corresponding option. Manual Update Server To display and configure manual update server’s settings. URL: Auto provisioning server address. User name: Configure if server needs an username to access, otherwise left blank. Password: Configure if server needs a password to access, ...
-
Page 33: Security
2.8. Security 2.8.1 Basic Sections Description Web Password Modify To modify user’s password. Current Password: The current password you used. New Password: Input new password you intend to use. Confirm Password: Repeat the new password. WWW.ACTIVEONLINE.COM.AU 1300 816 742...
