10 Attachment
Model Terminal
R/L1, S/L2, T/L3
U/T1, V/T2, W/T3
2021 -, +1, +2
B1, B2
R/L1, S/L2, T/L3
U/T1, V/T2, W/T3
2030 -, +1, +2
B1, B2
R/L1, S/L2, T/L3
U/T1, V/T2, W/T3
2042 -, +1, +2
B1, B2
298
Recommen Applicable
ded Gauge Gauge
AWG, kcmil AWG, kcmil
8 14 - 8
10 14 - 8
8 14 - 8
14 14 - 10
8 14 - 8
8 12 - 6
8 12 - 6
6 12 - 6
12 12 - 8
8 10 - 6
6 12 - 6
6 12 - 6
4 10 - 2
10 14 - 6
6 10 - 6
YASKAWA TOMPC71061753A YASKAWA AC Drive GA500 Installation and Operation Instruction
Wire
Terminal Screw
Stripping
Length
*1
Size
mm
10 M4
10 M4
10 M4
10 M4
- M4
10 M4
10 M4
10 M4
10 M4
- M5
10 M4
10 M4
18 M5
10 M4
- M5
Tightening
Torque
Shape
N∙m (in∙lb)
1.5 - 1.7
(13.5 - 15)
1.5 - 1.7
(13.5 - 15)
1.5 - 1.7
(13.5 - 15)
1.5 - 1.7
(13.5 - 15)
1.2 - 1.5
(10.6 - 13.3)
1.5 - 1.7
(13.5 - 15)
1.5 - 1.7
(13.5 - 15)
1.5 - 1.7
(13.5 - 15)
1.5 - 1.7
(13.5 - 15)
2.0 - 2.5
(17.7 - 22.1)
1.5 - 1.7
(13.5 - 15)
1.5 - 1.7
(13.5 - 15)
• ≤ AWG 10
2.3 - 2.5
(19.8 - 22)
• AWG 8 ≤
4.1 - 4.5
(36 - 40)
1.5 - 1.7
(13.5 - 15)
2.0 - 2.5
(17.7 - 22.1)
