3
ASSEMBLY
3.1
Package contents
The package contains the parts represented in the illustration, including a power cable with mains
plug. If one of the illustrated parts is missing, please contact your contract partner.
IV-M
IV-M1 & IV-M2 Pedal
IV-N
IV-N1 Screw
IV-N6 Screw
IV-N11 Adjusting lever
10
IV-M3 & IV-M4
Cover
IV-N2 Washer
IV-N7 Screw
IV-N13 Screw
IV-M5 Lever
IV-N3 Screw
IV-N9 Nut
IV-N15 Spring washer
IV-M6 Plug
IV-N4 Screw
IV-N10 Screw
IV-N16 Screw
BC70
