- Page 1 Assembly and Operating Instructions max. 150 kg ~ 30-60 Min. 48 kg L 108 | W 56 | H 134 CSTBX70iT.0.01 Art. No. CST-BX70i-T Exercise Bike BX70i Touch...
- Page 2 BX70i Touch...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS Console Display Button Functions Further Functions Programmes 3.4.1 Quick-Start Programme/Target Programme 3.4.2 Pre-set Programmes 3.4.3 Interval Programme 3.4.4 Heart Rate Controlled Programmes 3.4.5 Watt Programme 3.4.6 Virtual Training Routes Multimedia and Software Updates... - Page 4 ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT BX70i Touch...
- Page 5 With cardiostrong® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
- Page 6 This notice indicates potentially hazardous situations which, if not avoided, will result in death or serious injuries! NOTICE This notice indicates further useful information. Retain these instructions in a safe place for future reference, maintenance or when ordering replacement parts. BX70i Touch...
-
Page 7: General Information
GENERAL INFORMATION Check your TFT console regularly for possible software updates. If available, make sure to carry out the updates. Technical Data TFTdisplay of Speed in km/h Rotations per minute Training time in min Training distance Calorie consumption in kcal Heart rate (when using the chest strap) Watt Resistance system:... -
Page 8: Personal Safety
Make sure that nobody is within the range of motion of the equipment during training so as not to endanger you or other persons. ࣑ ATTENTION Do not insert any objects of any kind into the openings of the device. BX70i Touch... -
Page 9: Electrical Safety
Electrical Safety ⚠ DANGER In order to reduce the risk of an electric shock, always unplug the equipment from the mains socket immediately after your workout, before assembly or dismantling, and before maintenance or cleaning. Do not pull on the cable. ⚠... -
Page 10: Set-Up Place
10°C and 35°C). The equipment should not be used outdoors or in rooms with high humidity (over 70%) like swimming pools. A floor protective mat/equipment underlay can help to protect high-quality floor coverings (parquet, laminate, cork, carpets) from dents and sweat and can help to level out slight unevenness. BX70i Touch... -
Page 11: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. -
Page 12: Scope Of Delivery
In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠ If parts of the scope of delivery are missing or damaged, the assembly must not be carried out. BX70i Touch... -
Page 14: Assembly
Mount the front stabilizer (4) and the rear stabilizer (2) to the main frame (1) with screw (9). Turn the screws under the foot cap to set the appropriate height. Tighten the screws. Mount the cover of the wheel (23). BX70i Touch... - Page 15 Step 2: Assembly of the saddle Mount the seat (10) on the adjustment tube of the seat adjustment tube (11). Mount the seat adjustment tube (11) on the seat post (66) with a screw (16) and the quick- release knob (15). NOTICE The seat can be adjusted in vertical and horizontal direction, see fig.
- Page 16 Be careful not to pinch the cables during the following step. Slide the protective cover (28) onto the handlebar post (29). Secure the handlebar post (29) with four bolts (30), four spring washers (8) and four flat washers (7). BX70i Touch...
- Page 17 Step 4: Assembly of the handlebar Guide the two pulse cables of the handlebar (68) through the opening provided for this purpose in the handlebar post (29). ࣑ ATTENTION Be careful not to pinch the cables during the following step. Mount the fixed handlebar (32) on the handlebar post (29) with four bolts (9) (fig.
- Page 18 (29 & 68) (fig. b). Mount the fixing plate (50) to the handlebar post (29) with two bolts (46) (fig. c). Mount the bottle holder (47) to the handlebar post (29) with two bolts (46). BX70i Touch...
- Page 19 Step 6: Assembly of the pedals NOTICE The pedals and pedal straps are marked accordingly (left/right). Attach the pedal straps to the pedals (62R & 62L). ࣑ CAUTION Make sure that the pedals are screwed in completely. Fit the right pedal (62R) to the right crank (35R) by turning clockwise. Mount the left pedal (62L) on the left crank (35L) by turning it anticlockwise.
- Page 20 The equipment must not be connected to a multiple socket, otherwise it cannot be guaranteed that the equipment will be supplied with sufficient power. Technical errors can result. Plug the power plug into a wall outlet that complies with the instructions in the chapter on electrical safety. BX70i Touch...
-
Page 21: Operating Instructions
OPERATING INSTRUCTIONS NOTICE Familiarise yourself with all the functions and setting options of the device before starting training. Have the proper use of this product explained to you by a specialist. Console Display Display of the training time TIME Display range 0:00 - 99:59:59 SPEED Display of the current speed Display of the training distance... -
Page 22: Button Functions
Display of the current revolutions per minute (RPM) Display range 0 - 999 Button Functions Start/Pause: Tap to start and/or pause the training Stop Tap to stop the training Tap to increase a value Down Tap to decrease a value BX70i Touch... -
Page 23: Further Functions
Further Functions Settings Here you will find all setting options. Volume Here you can adjust the volume. Brightness Here you can adjust the brightness. Timezone Here you can adjust the date or the current time zone. Wifi Here you can connect the console to a wifi network. Here you can connect the console to a Bluetooth chest Heart Rate strap. -
Page 24: Programmes
Programmes There are a variety of programmes available to you. These include Quick Start programme: Target programme: Pre-set programmes: Interval programme: Heart rate programmes: Watt programme: You can also set your own virtual training routes via Google Maps. BX70i Touch... -
Page 25: Quick-Start Programme/Target Programme
3.4.1 Quick-Start Programme/Target Programme Tap QUICK START in the main menu. Set the values for the desired distance, time and/or calories for your training. NOTICE You can set one or more parameters. The set values are counted down to 0, the others are counted up accordingly. -
Page 26: Pre-Set Programmes
To start the training, tap START. You can manually adjust the resistance during the training. To pause the training, tap PAUSE. To stop the training, tap STOP. → When the training is finished, a summary of the recorded training parameters is displayed. BX70i Touch... -
Page 27: Interval Programme
3.4.3 Interval Programme Tap INTERVAL in the main menu. Set the values for the desired number of cycles, time, resistance and revolutions per minute for your workout. To start the training, tap START. The workout starts with a 1-minute warm-up. You can manually adjust the resistance during the training. -
Page 28: Heart Rate Controlled Programmes
To start the training, tap START. The resistance is adjusted according to your heart rate. The resistance cannot be adjusted manually. NOTICE If the console does not receive a pulse signal for 30 seconds, the programme will automatically stop. BX70i Touch... - Page 29 To pause the training, tap PAUSE. To pause the training, tap STOP. → When the training is finished, a summary of the recorded training parameters is displayed.
-
Page 30: Watt Programme
The resistance level is automatically adjusted according to the wattage you set. To pause the training, tap the following icon To stop the training, tap the following icon → When the training is finished, a summary of the recorded training parameters is displayed. BX70i Touch... -
Page 31: Virtual Training Routes
3.4.6 Virtual Training Routes Tap MAP YOUR ROUTE in the main menu. After you have started this mode, you must determine your current position. To do this, tap the following icon To switch to the worldwide Google Maps view, tap the following icon NOTICE If you are within China, you can also select the default region by tapping the following icon Select your start position and tap until the following icon appears... - Page 32 Abb. 1 Wattprogramm 1 BX70i Touch...
-
Page 34: Multimedia And Software Updates
To return to the main menu, tap the following icon To go back one page within the apps, tap the following icon To start the training, tap the following icon To stop the training, tap the following icon BX70i Touch... - Page 35 Beispielübersicht einer App Example of an app Overview of apps and possible software updates...
-
Page 36: Storage And Transport
After that, you easily can move the equipment to a new position. For long transport distances the equipment should be disassembled and safely packed. Select the new location by following the instructions in the section 1.4 of this manual. BX70i Touch... -
Page 37: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner. -
Page 38: Error Codes And Troubleshooting
Please note that the video may not be available in your language or with appropriate subtitles. If you cannot scan QR codes, you can access all Sport-Tiedje videos on YouTube by first opening YouTube and entering “Sport-Tiedje” in the search field. BX70i Touch... -
Page 39: Disposal
DISPOSAL At the end of its operational life, this equipment cannot be disposed of in normal household waste. Instead, it must be disposed of via an electricals recycling centre. Further information can be obtained from your local authority‘s recycling service. The materials can be recycled as per their symbols. -
Page 40: Recommended Accessories
We will be happy to advise you! chest strap floor mat chest strap contact gel silicone spray towels BX70i Touch... - Page 41 The serial number of your equipment is unique. It's located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: cardiostrong / ergometer Model Name: BX70i Article Number: CST-BX70i-2...
- Page 42 50805-2-0015-F0 M5x0.8x15L Belt 58004-6-1125-00 995 J6 Waved washer 55120-5-2705-DA D27*D20.3*0.5T D27*D20.3*0.5T Cover for wheel 832S0-6-2176-B0 93.2*64.7*62 Pulley 58008-6-1040-00 D260*19*2T Bolt M6x1.0x15L 50106-5-0015-C0 M6x1.0x15L Nylon nut M6x1.0x6T 55206-1-2006-CA M6x1.0x6T Crank axle 817S0-3-2903-00 Upper protective cover 81800-6-4580-BZ0 Handlebar post 815S5-3-2000-J0 BX70i Touch...
- Page 43 Allen bolt M8*1.25*50L 50308-5-0050-UF3 M8*1.25*50L, bolt cover 18600-6-2171-B0 D29*21(M8) Fixed handlebar 815S5-3-2400-B0 Screw cover D26*11L 81502-6-2779-B0 Anti-loosen nut M10*1.25*10T 70501-6-2775-N0 Left crank 58007-6-1082-D0 right crank 58007-6-1081-D0 Left chain cover 81502-6-4501-BZ0 Right chain cover 81502-6-4502-BZ0 Bolt M5*0.8*10L 54805-2-0010-N0 M5*0.8*10L Fixing Plate 815G0-6-1673-N0 20*27*4T Round cycle for chain cover...
- Page 44 Screw ST4*1.41*12L 52804-2-0012-F0 ST4*1.41*12L front left decorative cover 81502-6-4514-BZ0 front right decorative cover 81502-6-4515-BZ0 screw ST4.2*15L 52842-2-0015-F0 ST4.2*15L Power supply 261D8-6-2411-00 Power supply socket 26100-6-2413-00 Live line 734S0-6-3480-00 150L Netural line 734S0-6-3479-00 150L Allen spanner 58030-6-1031-N1 Spanner 58030-6-1035-N1 155*30*5T BX70i Touch...
- Page 45 Exploded Drawing 49 59 54 53 52 55 56 43 44 67 13 48 34 33 18 27 26 83 94 93 EMS73000-A04 RoHS...
- Page 46 WARRANTY Training equipment from cardiostrong® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline.
- Page 47 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.
- Page 48 Mo - Fr 08:00 - 18:00 09:00 - 18:00 09:00 - 18:00 Please find a detailed overview including address and opening hours for all stores of the Sport-Tiedje Group in Germany and abroad on the following website: www.sport-tiedje.com/en/stores BX70i Touch...
- Page 49 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Sport-Tiedje is Europe’s largest specialist store for www.sport-tiedje.co.uk home fitness equipment with currently 80 stores www.sport-tiedje.de/blog and one of the world’s most renowned online mail order companies for fitness equipment. Private customers order via the 25 web shops www.facebook.com/SportTiedje in the respective national language or have their desired equpiment assembled on site.
- Page 50 Notes BX70i Touch...
- Page 52 Exercise Bike BX70i Touch...
