- Page 1 WSP-BT200 MODEL (Kiosk&Ticket Printer) Rev. 3.1 All specifications are subjected to change without notice http://www.woosim.com...
- Page 2 Copyright ⓒ2018 by Woosim Systems Inc. All rights reserved. The information contained in this manual is the property of Woosim Systems Inc. And may not be reproduced in whole or in part without the prior written permission of Woosim Systems Inc. Trademark a registered trademark of Woosim Systems Inc.
- Page 3 150mm/sec high-speed printer. The 2inch thermal panel printer is most suitable for ticketing applications, such as transportation, coupons, industrial machine, lottery, ATM and kiosks. The general features of WSP-BT200 printer are as follows: Very silent printing thru direct thermal printing method.
- Page 4 Do not allow plastic film, erasers, or adhesive tape to touch the paper for long periods. ● Do not stack the thermal paper with diazo copies immediately after copying or wet-type copies. ● Do not use chemical glue. ● Always use the clean thermal paper. http://www.woosim.com...
-
Page 5: Table Of Contents
2.6. Sensor ................................13 3. Interface ................................14 3.1. UART (RS-232C or TTL)..........................14 4. Using the printer ...............................15 4.1. Control panel ............................15 4.2. The self test ..............................15 5. Consumable Parts .............................16 5.1. Recommended paper ..........................16 5.2. Printing position ............................16 6. Revision History ..............................17 http://www.woosim.com... -
Page 6: Outline
BT200 Rev. 3.1 WSP-BT200 Model name Interface A0 : UART Power None : DC 24V Model name Interface Spec. Wired Wireless RS-232C Bluetooth SC30 IrDA None RS-485 Parallel None Example) 1. Porti-S40 Serial/Bluetooth Part No. ⇒ S40/A1 2. Porti-SC30 Bluetooth Only Part No. ⇒ SC30/Z1 Note) The above table is the interface format which is supported. -
Page 7: Specifications
-10 °C ~ 50°C (operating) Temperature Environment -10°C ~ 70°C (storage) conditions 30% - 80% (operating) Humidity 10% - 90% (storage) MCBF (Mean Cycle Mechanical 37,000,000 lines Between failure) Head Approximately 50 Km <Table 1 > http://www.woosim.com... -
Page 8: Setting Up The Printer
BT200 Rev. 3.1 & & When unpacking your printer box make sure it contains the printer and all accessories. If any accessories are missing or damage, please contact your dealer for assistance. WSP-BT200 http://www.woosim.com... -
Page 9: Printer Features
BT200 Rev. 3.1 Connecting Ground Cable Ground(0V) or to the land, if Ground Cable is not correctly connected, it will cause malfunctioning or the printer will be damaged. http://www.woosim.com... -
Page 10: Dimensions
BT200 Rev. 3.1 http://www.woosim.com... -
Page 11: Replacing The Paper Roll
Do not use paper rolls that have the paper glued to the core because the printer can not detect the paper end correctly. 1. Make sure that the printer is not receiving data; otherwise, data may be lost. 2. Remove the used paper roll core if there is one. 3. Insert the paper roll as shown. http://www.woosim.com... -
Page 12: Power Supply
The WSP-T280 printer is equipped to an external supply electrical power. The functions assigned to the pins in the connector are as follows: WARNING A wrong connection of power supply connector could be damage the printer. Applicable connector : MOLEX 53014-0410 or equivalent. http://www.woosim.com... -
Page 13: Sensor
When using the general thermal paper, the sensor which detects the exhaust presence of the paper. ② Sensor 2 : Black Mark Sensor When using label paper etc., is detected with the black mark sensor. ③ Sensor 3 : Roll-End Sensor Detects the remainder condition of the paper. http://www.woosim.com... -
Page 14: Interface
BT200 Rev. 3.1 The WSP-BT200 printer has a UART(RS-232C or TTL) interface and is connected by means of a 3pin male connector. In the following table, the signals present on the connector are listed: Pin No Name Direction Function Output... -
Page 15: Using The Printer
3. Printer will print out the current status. (F/W version and set contents) 4. And then pattern of characters will be printed out. 5. Self-test will be finished automatically and turned to the standby status. In case printer does not work properly, please contact Woosim customer service center. ※ http://www.woosim.com... -
Page 16: Consumable Parts
Chemicals or oil may change the color of paper, or printed characters may fade. Change of paper color starts from approx. 70℃. Pay attention to heat, humidity and sun light. Color of paper may be changed by being scratched by nail or hard metal, etc. http://www.woosim.com... -
Page 17: Revision History
BT200 Rev. 3.1 Date Version Comments Aug. 23. 2018 Renewal (B5->A4) http://www.woosim.com...
