Technical Data

4 Technical Data
4.1 Physical Features
All specified data was measured with a nominal input voltage, at full load, and an
ambient temperature of 25 °C. The threshold value tolerances are subject to typical
fluctuations.
Physical Feature
Operating voltage
Level alarm inputs
Input current from GND to internal +5V typically 0.5 mA
Switch output, maximum switch
voltage
Switch output, maximum current load
Power input sleep
Power input connection
Weight
Dimensions (Width x Depth x Height)
Temperature range
Maximum allowed humidity
Table 1: Physical Features
16
Potentially lethal operating voltage!
Risk of fatal injury from electric shock.
Prior to any technical or mechanical work at the INSYS
Modem 56k AC/DC 4.2, switch the power off and secure
the INSYS Modem 56k AC/DC 4.2 against being switched
on again.
Caution!
Overvoltage and voltage peaks from the mains supply!
Fire hazard and damage of the product due to overvoltage.
Install suitable overvoltage protection.
Danger!
Value
minimum 10 V DC or 100 V AC
maximum 60 V DC or 240 V AC
Level HIGH = 4-12 V
Level LOW = 0-1 V
30 V (DC) / 42 V (AC)
1 A (DC) / 0.5 A (AC)
2 W
2.5 W
250 g (8.82 oz)
70 mm x 110 mm x 75 mm
0 °C – 55 °C
95% non-condensing
INSYS Modem 56k AC/DC 4.2
