Technical Data

5 Technical Data
5.1

Physical Features

All specified data was measured with nominal input voltage, at full load, and an
ambient temperature of 25°C. The limit value tolerances are subject to the usual
variations.
Physical Feature
Operating voltage
Power consumption
Reset input level
Current consumption of the active
reset input against GND (internal 3.3 V)
Weight
Dimensions (Width x Depth x Height)
Temperature range
Maximum permissible humidity
IP rating
Table 1: Physical Features
5.2

Technological Features

Technological Feature
Supported Standards
Ethernet port
Table 2: Technological Features
16
Value
minimum 10 V DC
maximum 60 V DC
approx. 3.5 W
HIGH level = 3-12 V (contact open or
voltage strength for external supply)
LOW level = 0-1 V
Typically 0.35 mA (when enabling the
input by connecting to GND)
190 g
55 mm x 110 mm x 75 mm
-20 °C – 55 °C
95% non-condensing
Housing IP40, Terminals IP20
Description
ADSL/ADSL2/ADSL2+ (G.992.1, G.992.2,
T1.413, G992.3, G.992.5) with optimised
AFE (Analogue Front End) designed to
meet ADSL (TR-067) and ADSL2+ (TR-
100) requirements
LLC encapsulation according to RFC1483
10/100 Mbit/s full/half duplex auto sense;
automatic detection of "crossover" or
"patch" wiring; dying gasp.
INSYS ADSL 1.0
