insys icom 56k Manual page 53

INSYS Modem 56k AC/DC 4.2
can be changed in the drop-down field (Page 38, Figure 8: HSComm
Modem - Alarm functions tab (pulse input active was selected), Position
3).
Moreover, it is also possible, to send the individual messages regardless
of the selected connection type to a fax device in addition. Check the
"Fax message" checkbox for this (Page 38, Figure 8: HSComm Modem -
Alarm functions tab (pulse input active was selected), Position 7). An
entry field for the recipient number is then displayed besides the
checkbox. Enter the number of the fax device to which all messages are
to be sent in addition here.
In order to disable the input event processing, select "Alarm input not
active" in the drop-down menu (Page 38, Figure 8: HSComm Modem -
Alarm functions tab (pulse input active was selected), Position 1).
Configuration with AT commands
In order to use simple alarming, specify the
number of the SMS service center first
(when sending alarms via SMS), which is
used to send the message, or the phone
number of the fax device or modem, to
which the message is to be sent. If an
outside line access code or dialling pause is
required, this must be specified here as
well. For this, use the command
In order to select the simple alarming via
SMS, specify the phone number of the
mobile phone, to which the message is to
be sent, as well. For this, use the command
In order to select the simple alarming as
collective message to a fax as well, specify
the phone number of the fax device, to
which the message is to be sent. For this,
use the command
In order to disable the fax message, the
phone number must be deleted. For this,
use the command
In order to prevent that the INSYS Modem
56k AC/DC 4.2 does not wait for a phone
number from the exchange (e.g. for
configurations with phone systems), the
dial tone detection can be turned off. For
this, use the command
AT&Z0=phonenumber
AT&Z2=phonenumber
AT&Z3=phonenumber
AT&Z3=
ATX3
Functions
53
