Specifications

32(1.26)
61(2.4)
148
(5.83)
190 (7.49)
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes
or modifications not expressly approved by party responsible for compliance could void the user' s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter (see ** ).
IC RSS warning
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may
not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for
the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that, the
equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. (1/2) This radio transmitter (identify
the device by certification number, or model number if Category II) has been approved by Industry Canada to operate with the antenna types listed
below with the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this list,
having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.
IC Radiation Exposure Statement:
This equipment complies with IC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter (see **).
** For the IVPC-DS, the equipment should be installed and operated with minimum distance 20 cm between the radiator & your body.
>>
Unit:mm (inches)
36(1.42)
16 (0.63)
Model
Video format
Video Recording file format
View angle
Audio direction
Network connectivity
Wi-Fi
Frequency
Frequency
Sub 1 G
Power
Battery life *
Battery charging time
Night vision
Operating temperature
Operating humidity
IP rate
Memory card **
* at 25℃ ** 4 GB microSD card is included.
Model
Audio direction
Network connectivity
Wi-FI
Frequency
Power
Battery life
Charging time
LCD display
Operating temperature
Operating humidity
- Specifications and designs are subject to change without prior notice.
- 7 -
°
IVPC-DS
H.264 720p HD/VGA
MP4
H135°/ V75°
Two ways (Full duplex)
Wi-Fi 802.11 b/g/n
2.4 GHz
916 MHz
10 to 24 V AC/DC or
Rechargeable battery (included)
2 months/1 year (battery saving OFF/ON)
10 h with 5 V DC, 1 A supply
IR lighting LED
-20℃ to 50℃ (-4℉ to 122℉)
< 90% (no condensation)
IPX5
microSD card; UHS-I 4 to 32 GB
IVPC-MS
Two ways (Full Duplex)
Wi-Fi 802.11 b/g/n
2.4GHz
AC adapter 5 V/1.5 A
Approximate 8 h in standby
10 h by included AC/DC adapter
7-inch Touch LCD 1,024 x 600
0°C to 40°C (32°F to 104°F)
< 90% (no condensation)
