Confirm Operation; Expanding The System - Optex IVPC-DS Installation Manual

<< >>
Retrofit wiring
- Existing cables and power source for a door chime can be used to power the IVPC-DS.
- Existing door button and chime are not used for this installation.
1 2
Existing doorbell
1
Turn off power. Disconnect all wires
from the existing chime.
OFF
4
Connect the power source to the
IVPC-DS. If necessary, use the bypass
cable (included) for the connection.
Bypass cable
Caution
!
*1 The back cover protects against water intrusion. Make sure nothing is interfering with it.
*2 If the power source is kept off, the IVPC-DS is driven by the inner battery.
It may cause unexpected system shutdown if power is not restored before the battery depletes.
6

Confirm operation

After completing installation, follow up with a final operation test:
1. Push the doorbell button on the IVPC-DS to confirm audio and video on the IVPC-MS or a device running the OPTEX Vision App.
2. Go through the settings section of the user manual to customize the settings.
3. Hand this guide and the user manual to the end user for safekeeping.
4. The information from
Reference

Expanding the system

- Refer to the product lineup information in the user manual if unsure of how the system can be expanded.
FRONT
Existing
TRANS chime
REAR
Power source
10 to 24 V AC/DC
2 Remove the existing doorbell.
5 Turn on IVPC-DS power. *2
1
can be used to expand the device network later on.
3
IVPC-DS
ON
- 6 -
FRONT
Existing chime
TRANS
(not used)
REAR
4 5
Power source
10 to 24 V AC/DC
3
Mount the IVPC-DS instead. *1
5
(Refer to Wired operation )
