What To Expect - Optex IVPC-DS Installation Manual

IVPC-MS
Unused
Micro USB port
(for battery charge)
Micro SD card slot
Speaker

What to expect

Collect information;
1
Set up for pairing;
2
Pair the IVPC-DS;
3
Choose the location;
4
Mount the IVPC-DS;
5
Confirm operation;
6
1
Collect information
- Ask the user for the Wi-Fi SSID and password.
Record them on the two lines below.
- Peel the Device ID (DID) QR code from the mounting plate of the IVPC-DS and place on the space provided below.
- Note the location name, changed Device password and Admin password set during the installation.
- Hand the user this page when the installation process is finished for their record.
Device password: default 123456
It is used when pairing the IVPC-DS with the IVPC-MS or a device running the OPTEX Vision App.
It is necessary to change at the first pairing.
Admin password: default 123456
Used when changing settings. It is necessary to change after the first settings change.
Place DS #1
Location name
Admin. password
Device password
Microphone
to register (pair) the IVPC system to the Wi-Fi network.
prepare each device for the pairing processes.
pair the IVPC-DS to the IVPC-MS or a device running the OPTEX Vision App and test them.
check the installation site to see if it meets performance needs.
install on the site.
final check of the operations and customize settings if necessary.
Wi-Fi router
SSID;
Password;
Place DS #2
QR Code QR Code
Volume UP/DOWN
(7 steps)
Power ON/OFF
Place DS #3
Place DS #4
QR Code
QR Code
- 2 -
< Accessories >
Stand
AC/DC adapter
(micro USB)
For iOS only
NOTE
When using a device operated by iOS,
following password may be required for pairing.
Wi-Fi direct
SSID; RVDP- xxxxxxxx
12345678
Password;
Place DS #5
QR Code
Place DS #6
QR Code
