Mount the IVPC-DS
- Choose battery or wired operation.
Battery operation
1
Fix the mounting plate.
<< >>
Battery charging
- Charging not needed for wired operation.
- Use the included USB cable with any USB
port power supply or charge station capable
of delivering 5 V DC at 1A or greater.
- Full charge time will be approximately 10 hours.
Caution
!
Please recharge only when temperature is +10°C to + 40°C.
Wired operation (New installation); 10 to 24 V AC/DC
- See "Retrofit wiring" on the next page, if replacing an existing door chime.
1
Make sure to turn
off power.
OFF
Replace the back
5
cover. *1
Caution
!
*1 The back cover protects against water intrusion. Make sure nothing is interfering with it.
*2 If the power source is kept off, the IVPC-DS is driven by the inner battery.
It may cause unexpected system shutdown if power is not restored before the battery depletes.
2
Mount the main unit.
1
Attach the
main unit.
2
Slide down.
(For battery charging)
(+50°F to +104°F)
2
Fix the mounting
plate.
6
Assemble the main unit.
1
Attach the
main unit.
2
Slide down.
- 5 -
Micro USB port
USB port: 5 V 1 A or greater power supply
Remove the back
3 4
cover.
7
Tighten the lock screw.
3
Tighten the lock screw.
Wire the power cables.
NOTE
Polarity is not a concern.
8
Turn on power. *2
ON
