Optex IVPC-DS Installation Manual page 3

2
Set up for pairing
IVPC-DS
1
Loosen the lock screw.
4
Power on.
Push the power on/off button.
Confirm LED is flashing blue & white.
This is the pairing mode.
(Hold the factory reset button if not in
the pairing mode.)
IVPC-MS
1
Plug in.
Plug into the
USB port.
Plug into an AC outlet.
Do not use other AC/DC
Caution
!
adapter than included.
<<
To use the system with a device running the OPTEX Vision App. (option)
Download OPTEX Vision
1
Visit either "App store"
or "Google play" .
Remove the mounting plate.
2
Slide the
main unit.
Pull off the main unit.
5
Replace the front cover.
1
1
2
Replace the
rubber bushing.
If having trouble with the cover,
make sure the bushing is not in the way.
2
Power on.
Press the button to turn on.
Confirm that the LED turns on.
2
Search "OPTEX Vision"
in the store.
OPTEX Vision
An internet connection is required.
- 3 -
3 Remove the front cover.
Remove the
rubber bushing.
2
Insert a flat driver bit to pry open.
6
Push the front cover to secure.
Push.
3
Use the stand for
convenience.
>>
3
Lift up.
1
2
Wait for startup screen.
OPTEX Vision App
The display shows the
startup screen.
Find "OPTEX Vision"
to download it.
