1. Important Notes

The charger must be installed following
the respective installation manual, that is
delivered with the charger.
Only the 3G/4G USB stick that is delivered by
Wallbox is compatible with this feature.
Only qualified technicians are allowed to
perform the installation as it is described in
this document.

2. Required Material and Tools

Provided by Wallbox:
• Wallbox Commander, Commander 2 or
Copper C/S/SB
• 3G/4G USB stick model provided by
Wallbox.
3. Installation of the 3G/4G USB Stick
STEP 1
Insert the SIM card in the 3G/4G USB stick by
removing its cover and inserting the card in
the SIM card socket. The SIM card must be
oriented according to the mark.
STEP 2
Power off the charger and remove the cover
following the instructions of its installation
manual.
3
Before the installation of the 3G/4G USB stick,
the Wallbox must be powered o and its cover
removed. After, the Wallbox must be properly
closed, as defined in its installation manual.
The availability and performance of charger
connectivity over the mobile network will
depend on the coverage provided by the
network operator on the given location.
Additionally Required:
• Standard size Subscriber Identity Module
(SIM) card with an active data plan.
• Philips and Torx screwdrivers
• Opening Card for Commander and
Commander 2.
3G/4G USB stick
SIM CARD
POSITION MARK
