- Page 1 COMMANDER Installation guide Guía de instalación Installationsanleitung Guide d’installation Installatiegids Guida per I’installazione Guia de instalacão Installasjonsveiledning Asennusopas Distributed by...
-
Page 2: Table Of Contents
Wallbox device. Any resulting damage from such actions is excluded from the warranty. The installation of the Wallbox device must be performed by a qualified electrician in accordance with the perceptive regulation. The information provided in this Installation Guide does not relieve the user of responsibility to follow all norms and standards or local regulations that may apply. -
Page 3: Safety Instructions
• Wallbox chargers can only be used under the operating parameters specified and within the normal ambient conditions described in the Product Description. • Do not use your Wallbox charger under adverse climatic conditions that could affect the vehicle or the Wallbox device. Do not open the cover in the rain. -
Page 4: Product Description
Through the myWallbox platform, you can monitor energy consumption, view charging history and schedule charging sessions. You even have the option of configuring your Wallbox so that it charges at the most cost-effective time of day. - Page 5 1 - 3.7kW M - 7m 2 - Type 2 2 - 7.4kW 3 - 11kW 4 - 22kW Your Wallbox box should contain the following: Components Mounting parts • Wallbox Commander with charging • 4x 6.3x40mm Screws cable (I-1) •...
-
Page 6: Installation Instructions
The Wallbox charger must be permanently connected to the electrical earth of the installation. Before installing or cleaning your Wallbox make sure that the power supply is switched off and there is no power in the system. The charger must be installed in a sufficiently ventilated location to ensure it remains cool. -
Page 7: Dimensions And Positioning Of The Device
3-B. 3-A. REAR CONNECTION • Step 3-A.1: In the back of your Wallbox an area with a thinner wall can be found; use a cutter or any sharp tool and make an incision for entry of the cable. - Page 8 In case it is needed to reopen the device, use only the tool (I-9) provided for this procedure included in the Wallbox box. The use of any other tool or means may cause damage in the charger, which wouldn't be covered by the product warranty.
-
Page 9: Startup
• Step 6-C.4: Enable the IT network button. 6-D USING WALLBOX APP (I-8) • Step 6-D.1: Download the Wallbox app available from Android Play Store or Apple App Store. • Step 6-D.2: Log-in using your account. • Step 6-D.3: Add your charger by clicking on the "+" button on the main page, introduce the SN and UID of your charger. -
Page 10: Maintenance
• Make sure that the power supply is turned off before you start cleaning your charger. • If you want to clean your Wallbox we recommend that you use a soft, dry or damp cloth. Do not use a spray or direct water stream to clean your Wallbox charger. - Page 11 EDIT FOR COMMANDER WBCM-0-2-4-0-001-B TILA SÄHKÖVIRTA(A) fi...
- Page 12 I-5.1 I-5.2 I-5.3 I-7. 2 I-7. 1...
- Page 13 I-7.4 I-7.3 OPENING TOOL IMAGE Distributed by e-Mobility Division, TransNet NZ Limited 78 Cryers Road East Tamaki Auckland, 2013 NEW ZEALAND +64 9 274 3340 | ev@transnet.co.nz | www.evc.co.nz...
