BILLY GOAT
Self-Propelled Vacuum Owner's Manual
Accessories
Caster Kit
Use on hard surface
for maneuverability.
P/N 840129
Part No 840245
®
MV650SPH and MV600SPE
Hose Kit
For vacuuming hard
to reach areas.
P/N 840116
Bag Liner Kit
To collect leaves,
thatch, and grass.
P/N 840134
1
Felt Bag Kit
Use on all dusty
conditions.
P/N 840194
Form No F060711D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MV600SPE and is the answer not in the manual?

Questions and answers

Related Manuals for Billy Goat MV600SPE

Summary of Contents for Billy Goat MV600SPE

  • Page 1 Caster Kit Use on hard surface For vacuuming hard for maneuverability. to reach areas. P/N 840129 Part No 840245 ® MV650SPH and MV600SPE Hose Kit Bag Liner Kit To collect leaves, thatch, and grass. P/N 840116 P/N 840134 Felt Bag Kit Use on all dusty conditions.
  • Page 2 MV650SPH Self-Propelled Vacuum Owner’s Manual CONTENTS Specifications and Sound/Vibration ... Instruction Labels ... Assembly Instructions ... 5-8 Operation ... 9-13 Maintenance and Troubleshooting ... 14-18 Illustrated Parts List ... 19-26 Go to http://www.billygoat.com Visitez http://www.billygoat.com Part No 840245 for French-Canadian translations of the product manuals. pour la version canadienne-française des manuels de produits Form No F060711D...

  • Page 3: Vibration Data

    Sunny 73.7 F (23.2 8.05 mph (3.6m/s) South 83.5% 29.91” Hg (101.31 kPa) MV600SPE Briggs and Stratton 122MO70110F1 6.25 (4.66 kW) 1qt (.9L) 0.63 qt (0.59L) 179 lbs (81.2 kg) 208 lbs (94.3 kg) 28” Wide x 62.5” Long x 45.5” High...

  • Page 4: Instruction Labels

    MV650SPH Self-Propelled Vacuum Owner’s Manual INSTRUCTION LABELS The labels shown below were installed on your BILLY GOAT replace them before operating this equipment. Item numbers from the Illustrated Parts List and part numbers are provided for convenience in ordering replacement labels. The correct position for each label may be determined by referring to the Figure and Item numbers shown.
  • Page 5 MV650SPH Self-Propelled Vacuum Owner’s Manual MV Vacuum Assembly Drawing Form No F060711D Part No 840245...

  • Page 6: Parts List

    MV650SPH Self-Propelled Vacuum Owner’s Manual PARTS LIST Part No 840245 Form No F060711D...

  • Page 7: Assembly Instructions

    MV650SPH Self-Propelled Vacuum Owner’s Manual ASSEMBLY INSTRUCTIONS ® Your BILLY GOAT MV Vacuum was shipped in one carton, completely assembled except for the Hood/Upper Handle Assembly. Mounting hardware for the Hood/Upper Handle Assembly is temporarily installed on the lower handle and the Housing assembly.
  • Page 8 MV650SPH Self-Propelled Vacuum Owner’s Manual 4. Attach upper handle brace to lower handle using corresponding hardware. Then repeat this step on the other side. 7. Attach rod end to rod (as in step 5). 8. Attach nozzle door rod to the lever with nozzle door closed and lever in hose kit position.

  • Page 9: Operation

    MV650SPH Self-Propelled Vacuum Owner’s Manual OPERATION PERATOR ONTROLS The operator’s position is at the rear of the machine between the handlebars. The operator should STAND in a position to allow both handlebars to be grasped firmly, which allows sufficient leverage to steer the machine. Operator’s controls are shown below. TARTING CHECK engine oil level before operating machine.

  • Page 10: Vacuum Nozzle Height Adjustment

    MV650SPH Self-Propelled Vacuum Owner’s Manual Secure the unit with left hand at the handle then pull starter rope with right hand to start engine. On Electric models only SECURE UNIT AT THE HANDLE WITH LEFT HAND DURING START PULL STARTER CORD slowly until resistance is felt. Then pull cord rapidly to avoid kickback. Move throttle control back to FAST position and allow engine to reach correct operating speed.
  • Page 11 MV650SPH Self-Propelled Vacuum Owner’s Manual ACUUM OZZLE DJUSTMENT The vacuum nozzle door adjusts for the maximum performance under various applications. Nozzle fully opened. This is ideal for turf application Nozzle half way opened. This is ideal for hard surface application Nozzle closed for OPTIONAL hose kit.

  • Page 12: Vacuuming Operation

    MV650SPH Self-Propelled Vacuum Owner’s Manual ACUUMING PERATION This machine is designed for vacuuming leaves, grass clippings, and other types of organic litter. Debris mixed with cans, bottles, and small amounts of sand can be vacuumed; however, it is not this machine's primary purpose.

  • Page 13: Clearing A Clogged Nozzle

    MV650SPH Self-Propelled Vacuum Owner’s Manual LEARING A LOGGED OZZLE DISCONNECT spark plug wire before servicing unit. 1. Shut engine off and wait for impeller to stop completely. 2. Disconnect spark plug wire. 3. Wearing durable gloves, remove clog. WEAR durable gloves. Clog may contain sharp materials. 4.

  • Page 14: Periodic Maintenance

    MV650SPH Self-Propelled Vacuum Owner’s Manual MAINTENANCE ERIODIC AINTENANCE Periodic maintenance should be performed at the following intervals: Maintenance Operation Inspect for worn or damaged parts. Check for excessive vibration Inspect for loose parts. Clean Debris Bag Lubricate clutch control lever (Use white lithium grease or equiv.) LOCATION 1 Lubricate height adjuster LOCATION 2 Check drive clutch cable tension.

  • Page 15: Impeller Removal

    MV650SPH Self-Propelled Vacuum Owner’s Manual MPELLER EMOVAL READ all safety instructions before servicing unit. DISCONNECT spark plug wire before servicing unit. Tools required: 1/2” socket, 3/8” drive ratchet, 3/8” drive extension, 3/8” drive universal joint, 3/8” drive pry bar or long screwdriver jack stands or similar device adequate to support weight of machine.

  • Page 16: Drive Belt Removal And Replacement

    MV650SPH Self-Propelled Vacuum Owner’s Manual Procedure: 1. Wait for engine to cool and DISCONNECT SPARK PLUG! 2. Engage the clutch lever then pull the unit back until it stops freewheeling. The clutch lever should engage around 2 5/16” of travel or 4 inches from tip of lever to handle. 3.
  • Page 17 MV650SPH Self-Propelled Vacuum Owner’s Manual NSTALLING RIVE HAIN READ all safety instructions before servicing unit. DISCONNECT spark plug wire before servicing unit. Tools required: 7/16” and 1/2” socket. 7/16” and 1/2” combination wrench. “Needle nose” pliers Flat head screwdriver Allow the engine to cool completely and DISCONNECT THE SPARK PLUG. 1.

  • Page 18: Troubleshooting

    MV650SPH Self-Propelled Vacuum Owner’s Manual IRING IAGRAMS TROUBLESHOOTING Problem Will not vacuum or has poor vacuum performance. Abnormal vibration. Engine will not start. Engine is locked, will not pull over. No self-propelling Self propelled drive will not release Noisy or broken chain Part No 840245 Bag Switch Circuit Schematic Diagram Possible Cause...

  • Page 19: Illustrated Parts List

    MV650SPH Self-Propelled Vacuum Owner’s Manual ILLUSTRATED PARTS LIST Nozzle Assembly Figure 1 Form No F060711D Part No 840245...
  • Page 20 8172007 WASHER 1/4" SAE ZP 840017 MV WHEEL BEARING 840117 SOLENOID ELEC START 840198 BRACKET SOLENOID MOUNT MV 8181007 WASHER LOCK 1/4" EXT TOOTH 8142001 NUT 1/4" FIN HEX ZP Part No 840245 MV650SPH MV600SPE QTY. QTY. Form No F060711D...
  • Page 21 MV650SPH Self-Propelled Vacuum Owner’s Manual Drive /Rear Axle Assembly Figure 2 Form No F060711D Part No 840245...
  • Page 22 8177010 SPLIT LOCK WASHER 1/4" 8041006 SCREWCAP 1/4"-20 X 1" HCS ZP 840017 MV WHEEL BEARING 804170 BATTERY 12 V 840095 BATTER HOLD DOWN 840228 CABLE HARNES ELECTRIC START ONE PIECE Part No 840245 MV650SPH QTY. MV600SPE QTY. Form No F060711D...
  • Page 23 MV650SPH Self-Propelled Vacuum Owner’s Manual Engine Assembly Figure 3 Form No F060711D Part No 840245...
  • Page 24 WASHER SPLIT LOCK 1/4" 840083 SPACER 1.50OD X .890ID X .5 THK 840215 TERMINAL 18-14 BLUE T-TAP 840213 SCREWCAP 1/4-20X5/8 GR. 5 840228 CABLE HARNESS ELECT START 100261 LABEL WARNING FUEL EN/SP Part No 840245 MV650SPH QTY. MV600SPE QTY. Form No F060711D...
  • Page 25 MV650SPH Self-Propelled Vacuum Owner’s Manual Hood Assembly Figure 4 Form No F060711D Part No 840245...
  • Page 26 LATCH RUBBER ASSEMBLY MV VAC PAL NUT 0.312 BAG DEBRIS MV VAC GROMMET RUBBER 5/8" OD X 3/8" ID LABEL MADE IN U.S.A. CABLE HARNESS ELECT START SWITCH BRACKET START SWITCH MV VAC LABEL START STOP EN/SP MV650SPH MV600SPE QTY. QTY. Form No F060711D...
