MV PUSH EU Owner's Manual
Push Multi-Vac Owner's Manual
CASTER KIT
Use on hard surface
For vacuuming hard
for maneuverability.
P/N 840129
IMPORTANT- READ CAREFULLY BEFORE USE AND KEEP FOR FUTURE REFERENCE.
Part No 840514
MV650HEU
Beginning Serial #: 020516001
Accessories
HOSE KIT
BAG LINER KIT
To collect leaves,
to reach areas.
thatch, and grass.
P/N 840116
P/N 840134
Original Instructions
FELT BAG KIT
Use on all dusty
conditions.
P/N 840194
1
LINER KIT
Interior housing liner
to decrease housing
wear.
P/N 840201
840514_B_HI
Advertisement
Related Manuals for Billy Goat MV PUSH EU
Summary of Contents for Billy Goat MV PUSH EU
