7.3
EDS File Revisions
The EDS files from Control Techniques have undergone several
revisions as specifications have been changed or tightened up. The
table below shows the compatibility with the most common DeviceNet
configuration tools.
EDS
Revision
1.x
2.x
3.x
7.4
Advanced EDS Files
Advanced EDS files provide access to the complete drive parameter set
for a specific version of software. This al so includes parameters for any
small option module that may be fitted to the drive. Advanced EDS files
must be created using the Advanced EDS File Compiler, available from
your local Control Techniques Drive Centre.
To use an advanced EDS file:
1.
Specify the Unidrive mode to be used.
2.
Specify the type of small option module fitted
3.
Specify the nearest matching software version
4.
Make a note of the "Product Code Elaboration" value specified for
#20.12.
5.
Build the EDS file.
6.
Install the EDS file into the DeviceNet configuration software.
7.
Set #20.12 as specified for the Unidrive
8.
Set #17.19 to 1 to store and reset the UD70. (See section 4.9)
When the network is re-scanned, the product code of the Unidrive will
have changed, and this should be matched to the EDS file that has just
been created.
26
DeviceNet
RSNetworx
Manager
OK
Not compatible
OK
V2.xx.xx and earlier
OK
V3.xx.xx
Issue Number: 2
