9.9.4

Revision

Class: 1 (0x1)
The revision code is the combination of the major and minor revision
codes, where the major revision code is the low byte, and the minor
revision code is the high byte.
Action
Read
9.9.5

Status

Class: 1 (0x1)
This attribute represents the current status of the entire device. Its value
changes as the state of the device changes.
b15 b14
b7 b6
R - Recoverable fault
U - Unrecoverable fault
9.9.6

Serial Number

Class: 1 (0x1)
All Control Techniques DeviceNet interfaces have a unique serial
number stored in the non-volatile memory.
9.9.7

Product Name

Class: 1 (0x1)
The Unidrive DeviceNet interface will return the string "UD77" when this
attribute is read.
Issue Number: 2
Instance: 1 (0x1)
Major Revision Minor Revision
#11.29 Mod 100
#11.29
100
Instance: 1 (0x1)
b13 b12 b11
Major
fault (U) fault (R)
b5 b4 B3
Configured
Instance: 1 (0x1)
Instance: 1 (0x1)
Attribute: 4 (0x4)
Attribute: 5 (0x5)
b10 b9 b8
Major Minor Minor
fault (U) fault (R)
b2 b1 b0
Owned
Attribute: 6 (0x6)
Attribute: 7 (0x7)
