RGBlink M3 Quick Start Manual page 7

: 5P
Position, Size and Control Area
CONTROL: Layer selection button.
5 SIZE: Size adjustment and crop setting.
POSTION Joystick: Position adjustment button.
DSK Edit Area
DSK: DSK effect editing button
6 ON: ON/OFF button
LEVEL Rotary Knob: Adjust the alpha of DSK layer.
BLEND Edit Area
BLEND: BLEND effect editing button
7 ON: ON/OFF button
LEVEL Rotary Knob: Adjust the blend width.
Input Sources Area
LED Indicator: The button 1/2/3/4/5/6/7/8 is lit when the signal or background input is
selected for use.
PGM area
BK: Indicating function, the button is lit when enable background function.
OSD: Indicating function, the button is lit when enable OSD function.
LOGO: Indicating function, the button is lit when enable LOGO function.
STILL: Indicating function, the button is lit when enable STILL function.
8
1/2/3/4/5/6/7/8: Each button is numbered and can be used as direct number entry
when values such as resolution and size.
PST/Aux area
BK: Editing function, the button is lit when enable background function.
OSD: Editing function, the button is lit when enable OSD function.
LOGO: Editing function, the button is lit when enable LOGO function.
STILL: Editing function, the button is lit when enable STILL function.
BLACK Button
