PST Mode

M3 use the 8 inch HD preview edit display, and with one HDMI preview output, it supports the functions as
below:
Signal Selection
Push any button in Input Sources Area, for example, push the button [5], the border of signal 5 will change to
yellow, and the signal in PGM monitor will be changed to signal 5.
Add or Delete Layer
Push any button of [1] to [4] in Layer/Aux Area to add or delete the layer.
Add layer: the light is lit.
Select layer: the light is flashing.
Delete layer: the light is off.
Freeze the Layer
Push the [FREEZE] button in Layer/Aux Area, the layer will be freeze, push the button again, the layer is live.
Multiview Presets
1. Push any button in Multiview Presets Area to select multiview layouts, including 1P, PIP CENT, SIDE BY SIDE,
3P, 4P and 5P.
2. Push the [CONTROL] button in Position, Size and Control Area to select the layer, each layer can select
different signal.
3. User can adjust the position, size, crop for the selected layer, and set DSK, BLEND and MASK.
Set the Position
1. Push the [CONTROL] button in Position, Size and Control Area to select the layer, the border of the selected
layer will change to green.
2. Swing the [POSITION] joystick in Position, Size and Control Area to adjust the position of the layer.
When swing the joystick to the left or right, the horizontal position will be changed.
When swing the joystick up or down, the vertical position will be changed.
Scale and Crop
Push the [SIZE] button in Position, Size and Control Area, and enter to the interface as follows:
