Power Button
POWER: When yellow light is lit, the device is standby, while when green light is lit, the
4
device is starting up.
LCD Display
LCD Display
8 inch full-color display.
PVW Monitor (left): Multiview preview.
PVW: Eight images and single image preview switching button.
CHNL: Custom the eight channels.
Rotary: For PVW menu selections, adjustment and confirmation.
1
PST/PGM Monitor (right): Preview edit.
PGM: For PST and PGM switching.
LOGO: Custom the logo.
OSD: Custom the OSD.
STILL: Custom the STILL.
AUX: Quick split for PGM/SPGM output card.
FMT: Output format setting button.
Rotary Knob: For PST menu selections, adjustment and confirmation.
Layer/Aux Button
Button 1/2/3/4: For adding or deleting the layer.
3
FREEZE: Freeze the image or video.
Multiview Presets Area
Multiview Presets
: 1P
: PIP CENT
2
: SIDE BY SIDE
: 3P
: 4P
