Moxa Technologies ioThinx 4530 Series User Manual page 7

ioThinx 4530 Linux Manual
3. Select Serial port setup.
4. Select A to change the serial device. Note that you need to know which device node is connected to the
ioThinx 4530 controller.
5. Select E to configure the port settings according to the Serial Console Port Settings table provided.
6. Select Save setup as dfl (from the main configuration menu) to use default values.
7. Select Exit from minicom (from the configuration menu) to leave the configuration menu.
8. Execute minicom after completing the above configurations.
user@PC1:~# minicom
Windows Users
NOTE These steps apply to the Windows PC you are using to connect to the ioThinx 4530 controller. Do NOT apply
these steps to the ioThinx 4530 controller itself.
Take the following steps to connect to the ioThinx 4530 controller from your Windows PC.
1. Download PuTTY
connection with the ioThinx 4530 controller in a Windows environment.
2. Once the connection is established, the following window will open.
http://www.chiark.greenend.org.uk/~sgtatham/putty/download.html
2-3
Getting Started
to set up a serial
