2.1 stanDaRDs & Regulations - ConDensate DisPosal
systeM no. 2 - ConDensate PuMP
Control panel
Burner
plug
Condensate pump
wired in to come
on with burner.
Condensate
pump
Out to drain.
ConDensate PuMP
(kit is available as an optional extra)
Inlet connected to
condensate trap
at base of boiler.
Condensate trap
Condensate pump can be positioned within
the casing of the boiler, on the base, fixed to
the casing of the boiler or mounted on the
wall alongside the boiler.
