APCI-3xxx
1

DEFINITION OF APPLICATION

1.1

Intended use

The board APCI-3xxx
(32-/64-bit) which is used as electrical equipment for measurement, control
and laboratory use as defined in the norm IEC 61010-1.
1.2

Usage restrictions

The board APCI-3xxx must not to be used as safety related part for securing
emergency stop functions.
The board APCI-3xxx must not be used in potentially explosive
atmospheres.
1.3

General description of the board

Characteristics
The board has up to 16 single ended input channels or up to 8 differential
input channels for processing analog signals. The following table shows the
most significant characteristics of your board:
Analog inputs: Single
ended (SE) or differential
(diff.)
Resolution
Throughput
Analog outputs
Resolution
TTL inputs/outputs
Timer
Counter
1
Common name for the boards APCI-3000, APCI-3006, APCI-3100, APCI-3106 und
APCI-3500.
must be inserted in a PC with PCI 3.3 V/5V
1

Table 1-1: Overview

APCI-3000 APCI-3006
Up to 16 (SE) Up to 16 (SE)
Up to 8 (diff.) Up to 8 (diff.)
12-bit 16-bit
100 kHz 100 kHz
- -
- -
24 24
3 (16-bit) 3 (16-bit)
3 3
Definition of application
APCI-3100 APCI-3106
Up to 16 (SE) Up to 16 (SE)
Up to 8 (diff.)
Up to 8 (diff.)
12-bit 16-bit
100 kHz 100 kHz
4 4
12-bit 12-bit
24 24
3 (16-bit) 3 (16-bit)
3 3
7
APCI-3500
-
-
-
4
12-bit
24
3 (16-bit)
3
