Speedrooter 91™
CAT. NO. DESCRIPTION
S91-100 Frame Complete
S91-101 Frame Only with Axle
S91-101-A Handle Support Knob (2)
S91-101-B Motor Support Bolt, Nut, & Washer
S91-101-C Cord Wrap Cap (2)
S91-103 Stair Climber with Belt (1)
S91-103-A Nuts, Bolts, & Washers (2)
S91-103-B Spacers (2)
S91-107 Plated Handle Assembly
S91-107-A Handle – Left
S91-107-B Handle – Right
S91-107-C 6" Handle Wheel
S91-107-D Axle for Handle Wheel
S91-107-E Bushings (2)
S91-107-F Felt Washers (2)
S91-107-G Bolts and Nuts (2)
S91-107-H Set Screws (2)
S91-108 Brake Rod
S91-108-A Roll Pin
S91-109 Brake Rod Handle with Knob
S91-109-A Knob for Brake Rod
S91-109-B Roll Pin
S91-109-C Brake Rod Latch with Screws
S91-110 10" Wheel with Retaining Cap (1)
S91-111 Wheel Retaining Cap (2)
S91-112 Wheel Spacer Washers (2)
S91-115 Axle
S91-116 Motor Support Spring
S91-118 Motor Support Platform
S91-118-C Nuts, Bolts, & Washers (4)
S91-120 Front Bearing Assembly
S91-120-A Front Bearing Knob
S91-120-D Bolts, Nuts & Washers (2)
S91-130 Rear Drum Shaft Clamp
S91-130-A Drum Clamp Knob
S91-130-D Mounting Bolts & Washers (2)
S91-400 Small Drum Complete with Shaft
and Distributor Tube (15")
S91-402 Drum Shell
S91-404 Drum Hub with Bearings
S91-404-A Bushings (2)
S91-405 Nuts, Bolts, & Washers (5)
S91-407 Shaft Washer
S91-410 Drum Connecting Cable (for 1/2" cables)
S91-410-A Nut, Bolt, & Washer
S91-420 Small Drum Distributor Tube Assem.
S91-421 Distributor Tube Only
S91-422 Bushing
S91-423 Retaining Ring
S91-424 Thrust Bearing Race
For Power Feed Parts List and Schematic Diagram please visit www.drainbrain.com.
Speedrooter 91 Parts List
CAT. NO.
S91-425
S91-430
S91-440
S91-440-A
S91-450
S91-452
S91-454
S91-455
S91-460
S91-460-A
S91-470
S91-471
S91-472
S91-473
S91-474
S91-475
S91-475-A
S91-480
S91-481
S91-482
S91-490
S91-490-A
S91-600
S91-600-3/4
S91-601
S91-602
S91-602-1
S91-603
S91-604
S91-605
S91-605-A
S91-605-B
S91-605-C
S91-605-E
S91-605-G
S91-605-H
S91-605-J
S91-605-N
S91-609-1/2
S91-609-3/4
S91-614
S91-TB
S91-GT
GTE
S91-DECAL
S91-VIDEO
10
DESCRIPTION
Distributor Tube Retaining Bolt
Drum Shaft
Inner Drum Cage
Bushing
Large Drum Complete with Shaft
and Distributor Tube (18")
Drum Shell
Drum Hub Bearings (2)
Bearing Spring
Drum Connecting Cable
(for 5/8" and 3/4" cables)
Nut, Bolt, & Washer
Drum Distributor Tube Assembly
Distributor Tube Only
Bushing
Retaining Ring
Thrust Bearing Race
Distributor Tube Retaining Knob
with Bearing Assembly
Bearing Assembly for Retaining Knob
Drum Shaft
Wear Washer
Spacer collar with Set Screw
Inner Drum Cage
Bushing
1/2 hp Motor Complete with Air Foot
Switch, Reverse Switch, & GFCI
3/4 hp Motor Complete with Air Foot
Switch, Reverse Switch, & GFCI
V-Belt (64")
V-Belt Pulley
Slip Clutch (Optional)
Knob for Mounting Stud
20 ft. Power Cord with GFCI
Air Foot Switch & Rev. Switch Assem.
Box Only with Cover & Screws
Foot Pedal and Hose
Cable Tie
Power Switch Diaphragm
Reverse Switch – 3-Way
Rubber Boot (Rental)
Barbed Adapter
Strain Relief Nut
Belt Guard (1/2 hp) with Slot
Belt Guard (3/4 hp) with Slot
Small Drum V-Belt (57")
Tool Box
Guide Tube for Speedrooter 91
Guide Tube Extension
Set of Safety Decals
Instructional Video
