Your Speedrooter XL is designed to
give you years of trouble-free, profitable
service. However, no machine is better
than its operator.
Read, understand and follow all safe-
ty warnings and instructions provided
with the product. Failure to follow the
warnings and instructions may result in
electric shock and/or serious injury.
Save all warnings and instructions for
future reference.
SAVE THESE INSTRUCTIONS!
Speedrooter XL
Operating Instructions
For 3" through 10"
(75mm—250mm)
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Speedrooter XL and is the answer not in the manual?

Questions and answers

Related Manuals for General Pipe Cleaners Speedrooter XL

Summary of Contents for General Pipe Cleaners Speedrooter XL

  • Page 1 ® Speedrooter XL Operating Instructions For 3” through 10” (75mm—250mm) Your Speedrooter XL is designed to give you years of trouble-free, profitable service. However, no machine is better than its operator. Read, understand and follow all safe- ty warnings and instructions provided with the product.

  • Page 2: General Safety Rules

    These instructions are intended to items could become wrapped around the cable and cause seri- familiarize all personnel with the safe ous injury. operation and maintenance procedures for the Speedrooter XL. Always wear safety glasses rubber soled, non-slip shoes. Use of this safety equip- This is the safety alert symbol.
  • Page 3 ® Speedrooter XL GENERAL POWER TOOL SAFETY WARNINGS* 3. Prevent unintentional starting. Ensure the switch is in the off- position before connecting to power source and/or BATTERY WARNING pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energizing power tools that have the Read all safety warnings, instructions, illustrations and specifica- switch on invites accidents.

  • Page 4: Specific Safety Information

    ® Speedrooter XL Specific Safety Information for Speedrooter XL Service 1. Only wear leather gloves. Never use any other type of glove, 1. Have your power tool serviced by a qualified repair person such as cloth, rubber, or coated gloves. Never grasp a rotating using only identical replacement parts.
  • Page 5 Drum Blade Foot Pedal Distributor Tube 4” Rotary 4RSB For Cutting Roots Saw Blade Large Speedrooter XL shown (Right) For removing loose objects or with Cable Guide Tube Retrieving RTR-2 broken cables. (Cat. # SXL-GT) Tool 26” Flexible Leader LE-3 Helps cable get through tight traps and bends.

  • Page 6: Operation

    ® Speedrooter XL OPERATION POWER CABLE FEED Before stepping on the foot pedal, pull cable from the drum and Feed Pressure Knob Feed Control Lever slide it into the drain as far as it will go. Tighten the knob at top of the Power Cable Feed so that the feed Reverse roller presses against the cable.

  • Page 7: Special Operations

    ® Speedrooter XL Set drum down so that distributor tube is pointing up. Unscrew 10. Be careful not to let the cutter get caught in the stoppage as you knob at the back of distributor tube. (See Figure 1.) This un- work through it.
  • Page 8 ® Speedrooter XL TO REMOVE DRUM DISCONNECT MACHINE FROM POWER SOURCE BE- FORE REMOVING DRUM FROM MACHINE! Remove belt guard by loosening the knob above the motor and pull belt guard forward. Press down on motor and slide V-Belt off of drum.

  • Page 9: Maintenance

    ® Speedrooter XL MAINTENANCE DAMAGED ROLLER Excessive use may wear a roller to the point of failure. It is recom- To keep your machine operating smoothly, it is essential that all bear- mended that all three rollers be replaced at the same time (Cat # PO- ings be lubricated.
  • Page 10 ® Speedrooter XL TROUBLE SHOOTING GUIDE (Table 3) Problem Probable Cause Solution Cable kinks or breaks. Operator forcing the cable. Do not force the cable. Let the cutter do the work. Too much slack between ma- Allow no more than two feet between machine and chine and drain.
  • Page 11 ® Speedrooter XL...
  • Page 12 ® Speedrooter XL General Wire Spring Co. 1101 Thompson Avenue McKees Rocks, PA 15136 412-771-6300 www.drainbrain.com © General Wire Spring Co. 2022 C-XLOI-0422...
