Your Speedrooter 92 is designed
to give you years of trouble-free, profita-
ble service.
However, no machine is
better than its operator.
Read, understand and follow all
safety warnings and instructions provid-
ed with the product. Failure to follow the
warnings and instructions may result in
electric shock and/or serious injury.
Save all warnings and instructions for
future reference.
SAVE THESE INSTRUCTIONS!
Speedrooter 92
Operating Instructions
For 3" through 10"
(75mm—250mm)
®

Advertisement

loading
Need help?

Need help?

Do you have a question about the P-S92-E-34 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for General Pipe Cleaners P-S92-E-34

  • Page 1 ® Speedrooter 92 Operating Instructions For 3” through 10” (75mm—250mm) Your Speedrooter 92 is designed to give you years of trouble-free, profita- ble service. However, no machine is better than its operator. Read, understand and follow all safety warnings and instructions provid- ed with the product.
  • Page 2 ® Speedrooter 92 Electric shock resulting death can occur if you plug this machine into an improper- ly wired outlet. If the ground wire is electrified, you can be electrocuted by just touching WARNING! Read and understand all the machine, even when the instructions.
  • Page 3 ® Speedrooter 92 GENERAL POWER TOOL SAFETY WARNINGS* 3. Prevent unintentional starting. Ensure the switch is in the off- position before connecting to power source and/or BATTERY WARNING pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energizing power tools that have the Read all safety warnings, instructions, illustrations and specifica- switch on invites accidents.
  • Page 4 ® Speedrooter 92 9. Keep handles and grasping surfaces dry, clean and free from 8. Only use the drain cleaner for the recommended drain sizes. oil and grease. Slippery handles and grasping surfaces do not Using the wrong size drain cleaner can lead to twisting, kinking or allow for safe handling and control of the tool in unexpected situa- breaking of the cable and may result in personal injury.
  • Page 5 ® Speedrooter 92 Ground Fault Circuit Interrupter (GFCI) Cable Application Chart (Table 1) Your machine is equipped with a ground fault circuit interrupter, which protects you against shock if a short circuit should occur. Check that Cable Size Pipe Size Typical Applications receptacle is properly grounded.
  • Page 6 ® Speedrooter 92 OPERATION The feed lever controls the feeding rate and direction of the ca- ble. Move the lever down to feed cable out of drum. The further SET-UP the lever is moved downward, the faster the cable will feed out. Move lever up to retract cable into drum.
  • Page 7 ® Speedrooter 92 SPECIAL OPERATIONS HOW TO REMOVE DRUM DISCONNECT MACHINE FROM POWER SOURCE IF CABLE GETS CAUGHT IN LINE BEFORE REMOVING DRUM! The motor can be reversed for a few seconds at a time to free the cable if it gets caught in line. (Note: if using Power Cable Feed, put- Remove belt guard by loosening the knob above the motor and ting motor in reverse will cause the feed control lever to operate oppo- pulling the guard forward.
  • Page 8 ® Speedrooter 92 HOW TO INSTALL DRUM Then guide the knurled portion of the Flexitube spring into the front post clamp. (See photo) DISCONNECT MACHINE FROM POWER SOURCE BEFORE INSTALLING DRUM! 10. With one hand on the cable in front of the front post, To install the inner drum, pull approximately 12 inches of cable push the cable down to from the drum.
  • Page 9 ® Speedrooter 92 MAINTENANCE DAMAGED ROLLER Excessive use may wear a roller to the point of failure. It is recom- To keep your machine operating smoothly, it is essential that all bear- mended that all three rollers be replaced at the same time (Cat # PO- ings be lubricated.
  • Page 10 ® Speedrooter 92 TROUBLE SHOOTING GUIDE (Table 3) Problem Probable Cause Solution Cable kinks or breaks. Operator forcing the cable. Do not force the cable. Let the cutter do the work. Too much slack between machine and Allow no more than two feet between machine and drain. drain.
  • Page 11 ® Speedrooter 92...
  • Page 12 ® Speedrooter 92 General Wire Spring Co. 1101 Thompson Avenue McKees Rocks, PA 15136 412-771-6300 www.drainbrain.com © General Wire Spring Co. 2023 C-92OI-0423...
