Your Speedrooter 91 is designed to
give you years of trouble-free, profitable
service. However, no machine is better
than its operator.
Read, understand and follow all safety
warnings and instructions provided with
the product. Failure to follow the warnings
and instructions may result in electric
shock and/or serious injury. Save all warn-
ings and instructions for future reference.
SAVE THESE INSTRUCTIONS!
Speedrooter 91
Operating Instructions
For 3" through 10"
(75mm—250mm)
™
Advertisement
Table of Contents
Related Manuals for General Pipe Cleaners Speedrooter 91
Summary of Contents for General Pipe Cleaners Speedrooter 91
- Page 1 ™ Speedrooter 91 Operating Instructions For 3” through 10” (75mm—250mm) Your Speedrooter 91 is designed to give you years of trouble-free, profitable service. However, no machine is better than its operator. Read, understand and follow all safety warnings and instructions provided with the product.
-
Page 2: General Safety Rules
These items could become wrapped around the cable and procedures for the Speedrooter 91. cause serious injury. This is the safety alert symbol. It is used to alert you to potential personal Always wear safety glasses injury hazards. Obey all safety mes-... -
Page 3: Work Area
Speedrooter 91™ GENERAL SAFETY RULES 10. DO NOT touch plugs or tools with wet hands. Reduces the risk of electric shock. Work Area Personal Safety 1. Keep work area clean and well lit. Cluttered benches 1. Stay alert, watch what you are doing and use and dark areas invite accidents. -
Page 4: Specific Safety Rules
11. Before starting each job, check that the cable in the drum is not broken or kinked, by pulling the Speedrooter 91 shown (Right) cable out and checking for wear or breakage. Al- with Cable Guide Tube ways replace worn out (kinked or broken) cables with (Cat. -
Page 5: Operation
Speedrooter 91™ Cable Application Chart (Table 1) POWER CABLE FEED Cable Size Pipe Size Typical Applications Feed Pressure Knob Feed Control Lever 3/4” Large Drains, Long Runs, 4” to 10” Roots (Large Drum) Reverse 5/8” 3” to 6” Floor Drains, Roots (Large Drum) 1/2”... -
Page 6: Special Operations
Speedrooter 91™ OPERATION 10. Be careful not to let the cutter get caught in the stop- page as you work through it. This can cause kinking 1. Before stepping on the foot pedal, pull cable from the and breaking of the cable. When you feel the cable drum and slide it into the drain as far as it will go. - Page 7 Speedrooter 91™ TO REMOVE DRUM 1. Remove drum from machine frame. (See TO RE- MOVE DRUM.) DISCONNECT MACHINE FROM POWER Set drum down so that distributor tube is pointing up. SOURCE BEFORE REMOVING DRUM FROM Unscrew knob at the back of distributor tube. (See MACHINE! Figure 1.) This unlocks the distributor tube from the...
-
Page 8: Maintenance
Speedrooter 91™ re-assembly. The top roller can now be removed. TO INSTALL CABLE IN DRUM 2. Remove the snap rings and thrust washers from the bottom housing cylinders. The bottom rollers can DISCONNECT MACHINE FROM POWER now be removed. SOURCE BEFORE INSTALLING 3. - Page 9 Speedrooter 91™ TROUBLE SHOOTING GUIDE (Table 3) Problem Probable Cause Solution Cable kinks or breaks. Operator forcing the cable. Do not force the cable. Let the cutter do the work. Too much slack between ma- Allow no more than two feet between machine and chine and drain.
- Page 10 Small Drum Distributor Tube Assem. S91-614 Small Drum V-Belt (57") S91-421 Distributor Tube Only S91-TB Tool Box S91-422 Bushing S91-GT Guide Tube for Speedrooter 91 S91-423 Retaining Ring Guide Tube Extension S91-424 Thrust Bearing Race S91-DECAL Set of Safety Decals S91-VIDEO Instructional Video...
- Page 11 Speedrooter 91™...
- Page 12 Speedrooter 91™ General Wire Spring Co, 1101 Thompson Avenue McKees Rocks, PA 15136 412-771-6300 www.drainbrain.com © General Wire Spring Co. 2009 C-91OI-0409...
