- Page 1 Quick Start Guide TSL2571EVM Ver. 1.3 TSL2571 Light-to-Digital Ambient Light Sensor...
- Page 2 Table of Contents Out of the box ........................3 Software installation ......................3 Connect Hardware ....................... 4 Start Application ........................4 Contact and Support ......................5 page 2/5...
- Page 3 Out of the box Each TSL2571 EVM comes with the following components: Controller board v2.1 • TSL2571 Daughterboard • USB Cable with A connector and mini B connector • Flash Drive with Application Software and Documents • Quick Start Guide (not shown) Software installation Most PCs should have one or more Universal Serial Bus (USB) ports.
- Page 4 Connect Hardware Plug the TSL2571 Daughterboard into the Controller board. (Figure 1) Always use ESD procedures when handling the EVM. Using the enclosed USB cable, plug the mini-B connector into the EVM module. Using the other end of the cable, plug the USB A connector into a USB port on the computer.
- Page 5 Installation Completely Successfully Remove Installation Contact and Support For detail in using the TSL2571 EVM please refer to the User’s Guide included in the documents. If any technical difficulties are encountered, use the Tech Support page at http://www. .com/Support to submit a technical support request anytime or call (972) 673-0759 (main) M-F 8AM-5PM CST You may also use http://www.
