- Page 1 Quick Start Guide TMG3992 EVM TMG3992 Light-To-Digital Color Ambient Light Sensor / Proximity Sensor Evaluation Kit with IRBeam™ Support Version 1.0...
- Page 2 Contents Out of the Box ............................3 Software Installation ..........................3 Connect Hardware ..........................4 Start the Application ..........................4 page 2/5...
- Page 3 Flash Drive with Application Software and Documents Figure 1 TMG3992 EVM Kit Software Installation Most PCs should have one or more Universal Serial Bus (USB) ports. Install the ams flash drive into an unused USB port. Double-click the Setup.exe file on the flash drive, or Click Start ->...
- Page 4 Connect Hardware Plug the TMG3992 Daughterboard into the Controller board. (Figure 1) Always use ESD procedures when handling the EVM. Using the enclosed USB cable, plug the mini-B connector into the EVM module. Using the other end of the cable, plug the USB A-connector into a USB port on the computer. Start the Application Click the Digital Light Sensors icon on the desktop.
- Page 5 Figure 8 Installation Completed Successfully Figure 9 Remove Installation Contact and Support For detail in using the TMG3992 EVM please refer to the User’s Guide included in the documents. If any technical difficulties are encountered, use the Tech Support page at www.ams.com/Support...
